Schurter LDT Series Illuminated Momentary Push Button Switch PCB Mount 19 mm Cutout SPST Red LED IP40 48V 0041.9141.3107

Schurter 0041.9141.3107 is an illuminated push button switch from the LDT Series designed for momentary actuation and PCB mounting. It features a 19 mm panel cutout size and a green round actuator with a red LED for indication. The switch is configured with a single-pole single-throw (SPST) contact arrangement and a normally open (NO) switch configuration.

This switch supports a maximum contact voltage of 48 V AC and 48 V DC, and can handle a contact current of up to 200 mA. It adopts solder terminal type connections suitable for secure PCB installation. The IP40 rating provides protection from solid objects larger than 1 mm, making it suitable for many indoor industrial and electronic applications.

Operating temperature ranges from -25°C to 60°C, which covers typical industrial ambient conditions. The switch complies with RoHS environmental standards, ensuring it is free from hazardous substances. The mechanical design includes a round actuator style and is intended for front panel mounting.

Typical use cases for the Schurter LDT Series illuminated push button switch include industrial control panels, automation equipment, electronic devices, and instrumentation that require a visible push button control with illumination feedback for operational status.

The switch features a green round actuator with red LED illumination. Designed for momentary switch operation with SPST contact configuration. Supports contact voltages up to 48 V AC and 48 V DC. Rated for a contact current of 200 mA with solder terminal type.

IP40 rating ensures basic protection against solid objects. Operates in temperatures from -25°C to 60°C. Complies with RoHS material and safety standards. Suitable for PCB mount applications in industrial and electronic use.
