EMERSON ? ASCO Pneumatic Solenoid Valve Pilot G 521 Series 1/4 in Port Size 24V DC 8 Bar 1050 L/min 52100090

EMERSON ASCO 52100090 Pneumatic Solenoid Valve Pilot G 521 Series is a precision-engineered valve designed for controlling pneumatic fluid power systems. This pilot-actuated valve operates at 24V DC and supports a port size of 1/4 inch with G standard threads, ensuring compatibility with standard pneumatic fittings.

Constructed from high-quality anodised aluminium with nitrile rubber (NBR) seals, it ensures excellent resistance to wear and chemical degradation. The valve maintains reliable operation across a temperature range of 5°C to 50°C, suitable for various industrial environments.

With a maximum operating pressure of 8 bar and flow rates of up to 1050 L/min, it delivers robust performance in pneumatic control applications. The valve function supports 5/3 and 5/2 configurations, providing two positions for precise directional control. It mounts via a base type, either individually or on manifolds, making it adaptable for manifold assemblies or standalone setups.

The valve features a height of 188.5 mm and width of 56.5 mm, designed for easy installation and integration into pneumatic systems. Additionally, it requires a minimum pilot pressure of 1.5 bar to ensure effective operation.

This series includes a selection of mini pneumatic valves available in multiple port sizes and types, enabling users to select the optimal valve for their industrial automation and pneumatic control needs. Manufactured in France, the EMERSON ASCO 52100090 valve exemplifies quality and reliability for fluid power applications in manufacturing, HVAC, automotive, and other industrial sectors.

The valve has a port size of 1/4 inch and uses G standard connection threads. Constructed from anodised aluminium with nitrile rubber (NBR) seals for durability. Operates at a maximum pressure of 8 bar and a maximum flow rate of 1050 L/min.

Designed for operating temperatures between 5°C and 50°C with a minimum pilot pressure of 1.5 bar. The valve features 2 positions and functions in 5/3, 5/2 modes for versatile control. Mounts with a base type configuration suitable for manifold fitting or standalone use.

Compact dimensions include height 188.5 mm and width 56.5 mm, supporting easy integration. Manufactured in France and part of the 521 series of mini pneumatic valves. Explore EnvMart for other high-quality pneumatic valves and automation components.
