Crouzet Electrical Linear Actuator 10 mm Stroke Length 45N Maximum Force 230V AC Synchronous Motor 80510001

Crouzet 80510001 Electrical Linear Actuator offers a precise 10 mm stroke length and a maximum load capacity of 45N, powered by a synchronous motor operating at 230V AC. This actuator is engineered for linear movement applications requiring consistent speed and reliable force without rotational output on the shaft.

The actuator achieves a constant speed of 3.33 mm/s, making it ideal for controlled linear positioning in industrial, automation, mechanical, and fluid power systems. It features an M3 threaded piston rod for easy integration into existing mechanical assemblies.

Operating under IP40 protection, this linear actuator is safeguarded against solid foreign objects larger than 1mm, suitable for controlled environments. It performs reliably within a temperature range from -5°C to 75°C, accommodating varied climatic conditions.

Constructed to meet multiple compliance standards such as CEI 529, EN 55 022, and EN 60 335-1, it ensures safety and quality consistency. The device weighs only 90 grams, facilitating lightweight installations where mass is a consideration.

The actuator includes a 250 mm cable length with a tolerance of +/-10 mm, providing sufficient wiring length for versatile mounting options. Note that the synchronous motor requires an external capacitor for operation, typically part number 494-9858.

Provides precise linear movement with a 10 mm stroke length. Maximum load capacity of 45 Newtons ensures efficient operation. Operates at a constant speed of 3.33 mm/s at 230V AC. Equipped with synchronous motor technology for stable performance.

Designed with an IP40 rating for protection against solid objects. Operates reliably between -5°C and 75°C ambient temperatures. Piston rod features an M3 thread for secure mounting. Compact and lightweight design with only 90 grams weight.

Conforms to industry standards including CEI 529 and EN 55 022. Includes 250 mm wire length with ±10 mm tolerance for installation flexibility.

This electrical linear actuator serves a wide range of industrial applications including mechanical machinery, process automation, HVAC systems, and manufacturing industries where precise linear displacement is critical.
