SMC Pneumatic Solenoid Valve Solenoid G 1/8, 24V, 3.96W, Die Cast Zinc Body PVQ31-5G-40-01F-H

SMC PVQ31-5G-40-01F-H pneumatic solenoid valve is a compact and precise proportional valve designed for fluid power applications. It utilizes a direct poppet valve construction, allowing smooth control of airflow by current modulation. Operating at 24 volts with a solenoid power consumption of 3.96 watts, this valve is ideal for industrial pneumatic systems requiring accurate flow regulation.

The body material is die cast zinc, providing a robust and corrosion-resistant structure suitable for long-term use. The valve features an O-ring type port with a connection thread standard and port size of G 1/8, engineered for reliable sealing and easy installation with female port gender.

With two ports and a base mount pattern for body porting, the valve offers flexible mounting options and unrestricted orientation. It supports vacuum applications and significantly reduces operational noise during opening and closing cycles, enhancing workplace comfort and system efficiency.

Operating pressures range up to a maximum of 0.7 bar and maximum pilot pressure of 0.7 bar, with a minimum pilot pressure of 0.25 bar. The device achieves a maximum flow rate of 100 liters per minute, making it suitable for applications such as air blow, spin control in handpieces, blood pressure gauge control, and vacuum chamber flow regulation.

The operating temperature range from 0°C to 50°C and fluorelastomer seals ensure performance in diverse environments with chemical resistance. This model complies with RoHS standards and is manufactured in Japan, guaranteeing high quality and reliability.

Typical industrial use cases include manufacturing, laboratory settings, pneumatic automation in commercial and HVAC systems, and water treatment flow control. The valve’s compact size (height 25mm, length 61mm, width 25mm) facilitates integration into complex systems.

Discover more pneumatic solenoid valves and related components in EnvMart’s industrial valves category for optimized fluid control solutions. The valve features a compact direct poppet construction for smooth flow rate control.

Die cast zinc body ensures durability and corrosion resistance. Suitable for vacuum applications with reduced noise during operation. Mounting orientation is unrestricted for versatile installation. Port size and thread standard are G 1/8 with O-ring port type and female port gender.

Maximum operating pressure is 0.7 bar, with a maximum flow rate of 100 L/min. Operating temperature ranges from 0°C to 50°C for wide environmental compatibility. Seal material is fluorelastomer, providing chemical resistance and sealing reliability.

Number of ports is 2 with a base mount pattern suitable for body porting. This valve complies with RoHS standards and is manufactured in Japan. Explore EnvMart for a comprehensive range of Pneumatic Solenoid Valves to meet your industrial automation and fluid control needs.
