EMERSON ? AVENTICS EMERSON AVENTICS Pneumatic Solenoid Valve 4/2 Solenoid/Spring Metric 57 Series 24V DC 2.1W 5727970220
Specifications
| Country of Origin | Hungary |
|---|---|
| Voltage | 24V dc |
| Brand | EMERSON ? AVENTICS |
| Body Material | Polyoxymethylene |
| Maximum Operating Pressure | 10 bar |
| Height | 56mm |
| Length | 120mm |
| Width | 35mm |
| Mount Type | PRS Strip |
| Series | 57 |
| Number Of Ports | 4 |
| Maximum Operating Temperature | 50°C |
| Port Type | Push-in |
| Port Size | M16 |
| Seal Material | Acrylonitrile Butadiene Rubber |
| Minimum Operating Temperature | -15°C |
| Actuation Type | Solenoid/Spring |
| Maximum Flow Rate | 700L/min |
| Connection Thread Standard | Metric |
| Minimum Pilot Pressure | 1.5bar |
| Valve Function | 4/2 |
| Solenoid Power Consumption | 2.1W |
Key Features
- Operates at a voltage rating of 24V DC with power consumption of 2.1W.
- Features a 4-port 4/2 valve function with push-in port type and M16 port size.
- Built with a polyoxymethylene body and acrylonitrile butadiene rubber seal material for durability.
- Operates within temperature range from -15°C to 50°C and maximum operating pressure of 10 bar.
- Compact dimensions with length 120mm, width 35mm, and height 56mm for easy installation.
- Designed to handle maximum flow rate up to 700 L/min suitable for various pneumatic automation tasks.
- Equipped with solenoid/spring actuation for reliable switching performance.
Product Description
EMERSON AVENTICS 5727970220 Pneumatic Solenoid Valve 4/2 Solenoid/Spring Metric 57 Series 24V DC operates at 24V DC with a power consumption of 2.1W, suitable for precise pneumatic control in industrial automation.
This solenoid valve features a polyoxymethylene body material combined with an acrylonitrile butadiene rubber seal, enabling dependable sealing and resistance to wear.
The valve function is 4/2, providing four ports with solenoid and spring actuation for effective fluid routing and control in pneumatic systems. It includes push-in type ports sized M16 with metric connection threads to fit standard pneumatic components.
Designed to withstand a maximum operating pressure of 10 bar and pilot pressure between 1.5 bar and 10 bar, it allows robust performance under demanding conditions. The operating temperature range from -15°C to 50°C makes it versatile across various environments.
With a maximum flow rate of 700 L/min, this valve supports high throughput in manufacturing, assembly lines, HVAC systems, and other fluid power applications.
Its compact dimensions of 120mm length, 35mm width, and 56mm height enable space-efficient installation without sacrificing performance. The mounting type is a PRS strip for straightforward setup.
This product is designed for use in industrial, manufacturing, and pneumatic automation settings where reliable fluid direction and control are critical. Manufactured in Hungary, it meets high quality standards ensuring longevity and operational stability.
Operates at a voltage rating of 24V DC with power consumption of 2.1W. Features a 4-port 4/2 valve function with push-in port type and M16 port size. Built with a polyoxymethylene body and acrylonitrile butadiene rubber seal material for durability.
Operates within temperature range from -15°C to 50°C and maximum operating pressure of 10 bar. Compact dimensions with length 120mm, width 35mm, and height 56mm for easy installation. Designed to handle maximum flow rate up to 700 L/min suitable for various pneumatic automation tasks.
Equipped with solenoid/spring actuation for reliable switching performance.
Explore more pneumatic solenoid valves and industrial valves in the Pneumatic Solenoid Valves category at EnvMart for comprehensive fluid control solutions suitable for your operational needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage rating of 24V DC with a power consumption of 2.1W.
The maximum operating pressure is 10 bar, allowing it to function effectively under demanding conditions.
This valve is designed to handle a maximum flow rate of up to 700 L/min.
The compact dimensions are 120mm in length, 35mm in width, and 56mm in height.
It is equipped with solenoid/spring actuation for reliable switching performance.
The operating temperature range is from -15°C to 50°C.
It features push-in type ports sized M16 with metric connection threads.
This model features a 4-port 4/2 valve function.
The body is made of polyoxymethylene, and the seal material is acrylonitrile butadiene rubber.
It is designed for PRS strip mounting, facilitating straightforward installation.
The minimum pilot pressure required is 1.5 bar.
This product is manufactured in Hungary.
