Finder 77 Series Solid State Relay 30 A Load, DIN Rail Mount, 480 V AC Load, 24 V DC Control 77.31.9.024.8051
Specifications
| Country of Origin | Italy |
|---|---|
| Brand | Finder |
| Height | 104.5mm |
| Length | 22.5mm |
| IP Rating | IP20 |
| Width | 60mm |
| Mount Type | DIN Rail |
| Series | 77 |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Screw |
| Switching Function | Random Switching |
| Maximum Load Current | 30A |
| Standards/Approvals | RoHS, UKCA |
| Maximum Load Voltage | 480V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 24V dc |
| Off State Leakage Current | 1mA |
Key Features
- Supports load voltage range from 48 to 480 V AC allowing flexible use in various systems.
- Control voltage range from 4 to 24 V DC enhances integration versatility.
- Compact DIN rail mount design with dimensions 22.5 mm width, 60 mm length, and 104.5 mm height.
- Operates reliably between -20°C and 80°C suitable for demanding environments.
- Features screw terminal type and SPST contact configuration for secure connections.
- Silent operation prevents electrical arcing and contact bounce improving system longevity.
- Complies with RoHS and UKCA standards ensuring safety and environmental compliance.
- Off state leakage current rated at 1 mA minimizing power loss when switched off.
Product Description
Finder 77.31.9.024.8051 is a high-performance solid state relay designed for efficient switching of loads up to 30 A with a maximum load voltage of 480 V AC. This solid state relay features a compact DIN rail mount form factor measuring 22.5 mm in width, 60 mm in length, and 104.5 mm in height, making it suitable for industrial and automation applications.
The control input voltage ranges from 4 to 24 V DC, providing broad compatibility with many control circuits. Its robust design supports operation within a temperature range of -20°C to 80°C, allowing reliable use even in challenging environmental conditions.
Equipped with screw terminals and an SPST contact configuration, this relay ensures secure connections with minimal maintenance. Its silent operation eliminates mechanical noise and electrical arcing, extending the relay's service life and reducing electromagnetic interference in control systems.
This model complies with RoHS and UKCA certifications, showcasing safety and environmental stewardship. Its random switching function and low off state leakage current of 1 mA provide efficient and safe control performance.
Additional benefits include high resistance to inrush currents, making it suitable for controlling motors, heaters, and other resistive loads in HVAC systems, industrial machinery, and process automation setups.
Supports load voltages from 48 to 480 V AC for wide application scope. Control voltage flexibility from 4 to 24 V DC for easy integration. Compact DIN rail mount suitable for dense panel installations. Operating temperature range of -20°C to 80°C for durable performance.
Screw terminal connections with SPST contact configuration. Silent switching extends equipment life and prevents noise. Meets RoHS and UKCA standards for compliance and safety. Low off state leakage current reduces power loss.
High inrush current tolerance for industrial operational reliability. Ideal for automation, HVAC control, and industrial resistive load management. Discover the comprehensive range of Finder Solid State Relays at EnvMart for your industrial automation, HVAC, and control system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 30 A.
It operates reliably within a temperature range of -20°C to 80°C.
The control voltage range is from 4 to 24 V DC, allowing for broad compatibility with various control circuits.
This model measures 22.5 mm in width, 60 mm in length, and 104.5 mm in height.
It features screw terminal connections, ensuring secure and reliable installations.
The maximum load voltage is 480 V AC, supporting a wide range of applications.
Yes, it complies with RoHS and UKCA standards, ensuring safety and environmental compliance.
The off state leakage current is rated at 1 mA, minimizing power loss when the relay is switched off.
It has an SPST contact configuration, which is suitable for various control applications.
This solid state relay is designed for DIN rail mounting, making it suitable for compact panel installations.
It features a random switching function, which enhances its operational versatility.
This solid state relay is manufactured in Italy.
