Finder 77 Series Solid State Relay, 30 A Load, 480 V AC Load, 24 V DC Control, DIN Rail Mount 77.31.9.024.8071

Finder 77.31.9.024.8071 is a high-performance Solid State Relay from the well-regarded 77 Series, engineered to control loads up to 30 A with a maximum load voltage of 480 V AC. It features a compact design optimized for DIN rail mounting, which facilitates easy integration in various electrical panels and industrial automation systems.

The relay requires a DC control voltage between 4 V and 24 V, allowing for compatibility with diverse control circuits. Its screw terminal type ensures reliable and secure electrical connections, suitable for demanding industrial environments.

Built for endurance and efficiency, this relay supports zero cross switching. This functionality is crucial for reducing sparking and electrical noise during switching, enhancing the longevity of connected equipment and maintaining system stability.

The device operates under an operating temperature range from -20°C to 80°C and features an IP20 ingress protection rating, making it suitable for indoor industrial applications with moderate environmental exposure.

Dimensions are optimized for space-saving installations, standing 104.5 mm tall, 60 mm wide, and 22.5 mm deep, making it adaptable to various control cabinet layouts.

With a minimal off-state leakage current of 1 mA, this solid state relay provides efficient power management. Manufactured in Italy, it complies with the UKCA and RoHS standards, ensuring quality and environmental responsibility.

Capable of handling a maximum load current of 30 amperes. Designed for mounting on DIN rails for industrial panel installation. Supports load voltages from 48 V AC up to 480 V AC. Control voltage range between 4 V DC and 24 V DC for flexible applications.

Features screw terminal connections ensuring secure wiring. IP20 rated for protection against solid objects larger than 12 mm. Operates reliably in temperatures from -20°C to 80°C. Incorporates zero cross switching to reduce electrical noise and prolong device life.

Compact dimensions measuring 104.5 mm height, 60 mm width, and 22.5 mm length. Low off-state leakage current of 1 mA for energy efficiency. Manufactured in Italy adhering to UKCA and RoHS standards.

This solid state relay is ideal for industrial automation, control systems, electrical panels, manufacturing equipment, and HVAC applications where reliable load switching and durability are essential. Explore more Solid State Relays on EnvMart for diverse load control solutions.
