Eaton Xboard Series Residual Current Circuit Breaker 80A 1-Pole 30 mA Type AC 500A Breaking Capacity 235402 PFIM-80/2/003-MW

Eaton 235402 PFIM-80/2/003-MW Residual Current Circuit Breaker (RCCB) is engineered for effective protection of electrical circuits in residential and commercial installations. It is rated for 80A with a single-pole configuration designed to detect earth leakage currents with a 30 mA trip sensitivity, providing enhanced safety against electric shock and fire risks.

The device features an instantaneous trip time and AC type tripping characteristic that ensures rapid disconnection upon detecting alternating current leakages. It can be mounted easily on standard DIN rails, facilitating streamlined installation and maintenance within consumer units such as the F&G Concept 2000 system.

The breaker has screw terminals designed for secure and stable electrical connections, supporting system reliability. Its compact dimensions (80 mm height, 70.5 mm depth, and 35 mm width) make it suitable for space-conscious panel designs. The high breaking capacity of 500A guarantees effective interruption of fault currents, critical in protecting wiring infrastructure.

Built to comply with RoHS directives and IEC/EN 61008 standards, this Eaton Xboard series model ensures compliance with international safety and environmental requirements. Designed and manufactured in Austria, it reflects Eaton’s commitment to quality and durability.

Instantaneous 30 mA trip sensitivity ensures rapid leakage detection. Type AC tripping characteristic suitable for AC earth leakage protection. DIN Rail mount for easy installation in consumer units. Robust screw terminals facilitate secure wiring connections.

Complies with RoHS and IEC/EN 61008 standards. Compact dimensions: 80mm height, 70.5mm depth, and 35mm width save panel space. High breaking capacity of 500A ensures reliable interruption of fault currents. Lever-type reset actuator for user-friendly manual reset after tripping.

Rated for dual AC voltages: 230V and 400V for versatile applications. Manufactured in Austria to stringent quality standards.

This residual current breaker is ideal for use in industrial, residential, and commercial electrical distribution panels to enhance personnel safety and equipment protection by preventing electric shock hazards and electrical fires.
