EMERSON ? ASCO Pneumatic Solenoid Valve Pilot G 1/8 Port Size 24V DC 52000009

EMERSON ASCO 52000009 Pneumatic Solenoid Valve - Pilot G 1/8 is engineered for precise control in pneumatic systems requiring reliable and efficient valve operation at 24V DC. This valve is designed for industrial, mechanical, fluid power, and automation applications where control of air flow and pressure is critical.

The valve features a robust anodised aluminium body combined with nitrile rubber (NBR) seals for enhanced wear resistance and longevity. Its compact dimensions of 26 mm width and 61 mm height make it suitable for manifold mounting or standalone use. The 520 series includes monostable, bistable, closed center, and open center options, with this model offering versatile 5/3 and 5/2 valve functions for complex air routing needs.

Operating parameters ensure functionality within a maximum pressure of 8 bar and a maximum flow rate of 600 L/min. Designed to withstand operating temperatures from 5°C to 50°C, it necessitates a minimum pilot pressure of 1.5 bar to actuate reliably. The valve uses a G 1/8 port size with tap port type and connection threads standard G 1/8, suitable for standard pneumatic fittings.

This valve is manufactured in France adhering to stringent quality controls. The base mount type provides secure and stable installation in industrial pneumatic circuits. The valve is engineered for precise and reliable pneumatic control.

Robust anodised aluminium body with nitrile rubber seals guarantees durability. Compatible with manifold mounting or individual installation. Operates efficiently within 5 to 50 degrees Celsius and up to 8 bar pressure. Supports high flow rates up to 600 liters per minute.

5-port design with versatile valve functions: 5/3 and 5/2 for varied control schemes. Provides user-friendly installation with standard G 1/8 thread connections. Ensures consistent industrial performance for automation and fluid power systems.

Part of the 520 series designed for robust pneumatic applications. Manufactured in France with stringent quality standards.

This Pneumatic Solenoid Valve suits a broad range of industrial uses including manufacturing automation, pneumatic tool operation, HVAC systems, and other fluid power applications. Its precise pilot actuation and rugged construction make it ideal for demanding environments. Explore more pneumatic control valves and industrial automation components with EnvMart for your application needs.
