Siemens Inverter Drive 5.5 kW 3 Phase SINAMICS G115D Series 480V 26.4A 6SL3520-3XA25-5AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-3XA25-5AF0 |
| IP Rating | IP65, IP66 |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 5.5kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 26.4A |
| Standards/Approvals | UL, CE, C-Tick (RCM), cUL, EAC, KCC, REACH, SEMI F47 |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
Key Features
- High efficiency inverter drive compatible with SIMOGEAR 2KJ8 geared motors.
- Supports three-phase asynchronous motors with IE3 efficiency or synchronous reluctance motors with IE4 efficiency.
- IP65 and IP66 protection ratings ensure robust performance in industrial environments.
- Wide operating temperature range from -30°C to 55°C for versatile use.
- Integrated safety features including STO and fail-safe digital input (F-DI) or PROFIsafe.
- No control cabinet required, enabling machine-mount installation for space and cooling efficiency.
- Suitable for horizontal conveyor applications with speed control and encoderless vector control.
- Modular design allows quick installation, cabling, and commissioning.
Product Description
Siemens 6SL3520-3XA25-5AF0 inverter drive is a 5.5 kW, 3-phase device from the SINAMICS G115D series, designed for industrial automation with a 480V supply voltage and a maximum output current of 26.4 A. This converter supports SIMOGEAR 2KJ8 geared motors and three-phase asynchronous motors with IE3 efficiency class or high-efficiency synchronous reluctance motors with IE4 class, making it ideal for efficient power and speed control in modern conveyor systems.
The device features comprehensive IP65 and IP66 ingress protection ratings, ensuring durability and operational reliability in harsh industrial and outdoor environments. It operates efficiently over a wide temperature range from -30°C to 55°C, enabling usage in diverse climatic conditions.
Integrated safety features include the Safe Torque Off (STO) function combined with fail-safe digital inputs or PROFIsafe, enhancing operational safety. The modular design eliminates the need for a separate control cabinet, allowing the drive to be mounted directly on machines, which reduces space requirements and cooling demands.
This inverter drive supports various conveyor system applications, ranging from basic speed control to complex encoderless vector control, ensuring versatile and precise motor operation. Compliance with multiple international standards such as UL, CE, C-Tick (RCM), cUL, EAC, KCC, REACH, and SEMI F47 confirms its quality and safety suitability in global markets.
High efficiency inverter drive compatible with SIMOGEAR 2KJ8 geared motors. Supports three-phase asynchronous motors with IE3 efficiency or synchronous reluctance motors with IE4 efficiency. IP65 and IP66 rated for robust industrial use.
Operating temperature range from -30°C to 55°C. Integrated STO safety function with fail-safe inputs. Machine-mount installation with no control cabinet required. Suitable for conveyor system applications with speed and vector control.
Modular design for quick installation and commissioning. Meets UL, CE, C-Tick (RCM), cUL, EAC, KCC, REACH, SEMI F47 standards. Made in the United Kingdom by Siemens.
Ideal for industrial automation, manufacturing plants, conveyor systems, and process control applications requiring reliable and energy-efficient Inverter Drive solutions. Explore more Siemens automation and control gear products with EnvMart for enhanced industrial performance.
