Siemens Inverter Drive SINAMICS G115D Series 4 kW 3 Phase Wall Mount 480V 20.4 A 6SL3520-0XA04-0AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-0XA04-0AB0 |
| IP Rating | IP65, IP66 |
| Mount Type | Wall |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 4kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 20.4A |
| Standards/Approvals | CE, C-Tick (RCM), cUL, EAC, KCC, REACH, SEMI F47, UL |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
| Compatible Motor Type | AC Motor |
Key Features
- Wall mount design with IP65 and IP66 protection rated for harsh environments.
- Supports output frequency up to 550Hz suitable for various motor speed applications.
- Compatible with AC motors, optimized for SIMOGEAR geared motors with efficiency class IE2.
- Operational temperature range from -30°C to 55°C enables wide usage conditions.
- Maximum output current rating of 20.4 A ensures stable motor drive performance.
- Complies with multiple international standards including CE, UL, and REACH for safety and environmental compliance.
- Designed for horizontal conveyor systems featuring encoderless vector control capabilities.
- Durable build from United Kingdom origin with IP65/66 and UL type 4X enclosure for industrial reliability.
Product Description
Siemens 6SL3520-0XA04-0AB0 inverter drive is a high-performance SINAMICS G115D series product designed for reliable motor control in industrial environments. It features 4 kW power capacity powered by a three-phase 480V supply delivering a maximum output current of 20.4 A. The wall mount converter unit is engineered for compatibility with SIMOGEAR 2KJ8 geared motors and three-phase asynchronous AC motors with IE2 efficiency classification, fulfilling energy-saving and operational efficiency needs.
This inverter supports a wide output frequency range up to 550Hz and operates reliably within a temperature span from -30°C to 55°C, making it suitable for diverse industrial applications such as conveyor systems with encoderless vector control. The device holds multiple global certifications including CE, cUL, UL, EAC, KCC, and complies with REACH regulations, emphasizing its adherence to safety and environmental standards.
The rugged IP65 and IP66 rated enclosure and UL type 4X protection ensure robustness against dust and water ingress, suitable for demanding industrial conditions. The Siemens inverter drive simplifies installation and maintenance with a new design focused on quick setup and easy cabling. Its advanced RFI suppression filter categorized as C2 reduces electromagnetic interference, further supporting industrial workplace safety.
Originating from the United Kingdom, this SINAMICS G115D drive is a vital component in automation and control gear, particularly suited for material handling, manufacturing, and conveyor systems within sectors demanding reliable and efficient variable speed motor drives. It is a Better World product contributing to energy savings, thereby promoting sustainability in industrial operations.
Wall-mounted inverter converter unit with advanced energy efficiency. Compatible with SIMOGEAR geared motors and asynchronous AC motors. Encoderless vector control for conveyor system applications. Wide operating temperature range for flexible industrial environments.
IP65, IP66, and UL type 4X rated for protection against dust and water. Comprehensive global certifications assure product compliance. Incorporates RFI suppression filter for reduced electromagnetic interference. Designed for quick installation and commissioning in industrial settings.
For professionals seeking industrial-grade Inverter Drives, Siemens SINAMICS G115D series 6SL3520-0XA04-0AB0 offers robust performance and reliability. Explore more industrial automation and motor control products at EnvMart to find compatible components and advanced solutions.
