SMC Pneumatic Solenoid Valve - 5/2 Solenoid G 1/8 Port Size Die Cast Aluminium Body 24V dc VZ5000
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 24V dc |
| Brand | SMC |
| Body Material | Die Cast Aluminium |
| Maximum Operating Pressure | 0.7 Mpa |
| Model | VZ5000 |
| Mount Type | Stand Alone |
| Series | VZ5000 |
| Number Of Ports | 5 |
| Maximum Operating Temperature | 50°C |
| Number of Positions | 3 |
| Port Size | 1/8 in |
| Seal Material | Nitrile Rubber (NBR) |
| Minimum Operating Temperature | -10°C |
| Actuation Type | Solenoid |
| Maximum Flow Rate | 588NL/min |
| Connection Thread Standard | G 1/8 |
| Mount Pattern | DIN |
| Minimum Pilot Pressure | 0.1MPa |
| Valve Function | 5/2 |
| Electrical Connection Type | 3-Pin Plug |
| Solenoid Type | Double |
| Solenoid Power Consumption | 2.1W |
Key Features
- Constructed with durable die cast aluminium body for long-lasting service.
- Double solenoid type with 3 positions ensures reliable pneumatic control.
- Rated maximum operating pressure of 0.7 MPa and maximum flow rate of 588 NL/min.
- Operates within temperature range of -10°C to 50°C with Nitrile Rubber (NBR) seals.
- Mount type is stand alone with DIN mount pattern for easy installation.
- Electrical connection via a 3-pin plug supports efficient operation.
- Low solenoid power consumption of 2.1 W optimizes energy use.
- Suitable for industrial pneumatic applications requiring precise valve function of 5/2.
Product Description
SMC EVZ5223-5MOZ-01F-Q Pneumatic Solenoid Valve belongs to the VZ5000 series, designed for 5/2 valve function applications. It features a robust die cast aluminium body ensuring durability and resistance to industrial environments. This valve operates with a 24V dc power supply and utilizes nitrile rubber (NBR) seals for effective sealing performance across a temperature range of -10°C to 50°C.
The valve supports a maximum operating pressure of 0.7 MPa and a maximum pilot pressure up to the same value, allowing for precise control of pneumatic circuits. With a maximum flow rate of 588 NL/min, it provides efficient airflow in pneumatic systems. The double solenoid actuation and three-position design enable flexible control, while the standard G 1/8 threaded port size facilitates integration with existing pneumatic piping.
Mounting is stand alone with a DIN pattern, simplifying installation and maintenance. Electrical connections employ a 3-pin plug for reliable communication with control systems. The valve incorporates a manual pulse control feature and non-locking manual override, enhancing operational versatility.
This valve is well-suited for a variety of industrial uses including manufacturing automation, process control, and pneumatic machinery applications. It supports manifold systems and direct PLC operation due to its low power consumption.
Die cast aluminium body for strength and corrosion resistance. Double solenoid double acting 5/2 valve configuration ensures dual control. 24V dc voltage rated for industrial control voltage standards. Precision sealing with nitrile rubber (NBR) seals.
Supports maximum pressure of 0.7 MPa and flow rate of 588 NL/min. Mount type stand alone with DIN mounting pattern for versatile installation. 3-position valve operation with manual pulse control and override. Electrical connection via 3-pin plug suited for industrial environments.
Manufactured in France to high quality standards.
For pneumatic valve requirements in industrial automation, hydraulic and pneumatic tooling, and fluid power systems, the SMC VZ5000 series EVZ5223-5MOZ-01F-Q valve is a reliable, efficient choice. Explore more valves and pneumatic components in the Industrial Valves & Valve Fittings category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 0.7 MPa.
It has a maximum flow rate of 588 NL/min.
The valve operates within a temperature range of -10°C to 50°C.
It employs a 3-pin plug for electrical connections.
The port size is G 1/8.
The body is made of die cast aluminium and it features nitrile rubber (NBR) seals.
This model has three positions for flexible control.
The solenoid power consumption is 2.1 W.
It is designed for stand-alone mounting with a DIN mount pattern.
This valve features double solenoid actuation.
It is manufactured in France.
This solenoid valve is suitable for industrial pneumatic applications, including manufacturing automation and process control.
