ABB System Pro M Compact S200 Miniature Circuit Breaker 4-Pole 6A Type Z 400V AC 110V DC 2CDS254001R0258 S204 Z 1.6A - 10 KA

ABB 2CDS254001R0258 S204 Z 1.6A - 10 KA System Pro M Compact S200 miniature circuit breaker is engineered to deliver superior electrical protection in industrial, commercial, and automation applications. This 4-pole MCB provides 6A current rating with a type Z tripping characteristic, making it suitable for protecting sensitive electronic circuits against overloads and short circuits.

The device is rated for 400 V AC and 110 V DC voltages and is designed to handle breaking capacities up to 20 kA, ensuring high resilience during fault conditions. The compact design, measuring 88 mm in height, 70 mm in width, and 69 mm in depth, supports efficient use of panel space. It is mounted conveniently on DIN rails and utilizes reliable screw terminal connections for secure wiring.

Compliance with IEC/EN 60947-2 and UL 1077 standards guarantees adherence to international safety and performance criteria. The aluminium chloride tripping mechanism enhances protection accuracy and durability. With an IP20 rating, it safeguards internal components against solid foreign objects and provides limited protection for users.

The MCB supports operation in harsh ambient conditions withstanding temperatures from -25 to +55 °C and safe storage from -40 to +70 °C. Originating from Germany, this breaker reflects stringent quality and manufacturing precision.

4-pole miniature circuit breaker with 6A rating. Type Z trip curve suited for sensitive electronics. Rated for 400 V AC and 110 V DC voltages. Breaking capacity of 20 kA to ensure circuit protection. DIN rail mountable with screw terminal connections.

Compact dimensions: 88 mm height x 70 mm width x 69 mm depth. Compliant with IEC/EN 60947-2 and UL 1077 standards. Aluminium chloride tripping mechanism enhances reliability. IP20 rated for protection against solid objects.

Ambient operational temperature range: -25°C to +55°C. Manufactured in Germany for quality assurance.

Ideal for integration in electrical panels for industrial automation, commercial buildings, and electrical infrastructure, this ABB miniature circuit breaker ensures robust protection, safety, and operational reliability. For more electrical protection products, explore the Miniature Circuit Breaker category on EnvMart.
