ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 3A, Type Z, 440V AC, 6 kA 2CDS254001R0318 S204 Z 3A - 10 KA

Free Delivery in India | Lowest Global Shipping Charges

ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 3A, Type Z, 440V AC, 6 kA 2CDS254001R0318 S204 Z 3A - 10 KA



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Germany
Range	System Pro M Compact
Brand	ABB
Height	88mm
Model	2CDS254001R0318 S204 Z 3A - 10 KA
Depth	69mm
IP Rating	IP20, IP40
Width	70mm
Mount Type	DIN Rail
Current Rating	3A
Series	S200
Ambient air temperature	Operation -25 ... +55 °C, Storage -40 ... +70 °C
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	4
Standards/Approvals	UL1077, IEC/EN 60947-2, IEC/EN 60898-1
Rated AC Voltage	440V ac
Tripping Characteristics	Type Z
Better World Claim	Designed for Disassembly
Tripping Mechanism	Anaerobic Adhesive

Key Features

Offers a breaking capacity of 6 kA at 440V AC for effective fault interruption.
Designed for mounting on DIN rails, facilitating easy installation.
Features a screw-type terminal for secure electrical connections.
Rated for operation in ambient temperatures ranging from -25°C to +55°C.
Conforms to international standards UL1077, IEC/EN 60947-2, and IEC/EN 60898-1.
Equipped with anaerobic adhesive tripping mechanism for precise protection.
Compact dimensions of 88mm height, 70mm width, and 69mm depth optimize panel space.
IP20 and IP40 protection ratings ensure safety against accidental contact and ingress.

Product Description

ABB 2CDS254001R0318 S204 Z 3A - 10 KA Miniature Circuit Breaker is a high-quality S200 series device designed to protect electrical circuits by interrupting overload and short-circuit faults. This 4-pole circuit breaker supports a current rating of 3A and trip characteristic type Z, suitable for sensitive protection in industrial, commercial, and residential electrical installations.

Its breaking capacity of 6 kA at 440V AC ensures reliable fault clearance, minimizing damage to electrical infrastructure. Designed for DIN rail mounting and equipped with screw terminals, it facilitates straightforward and secure installation within electrical panels.

The device complies with stringent safety and performance standards, including UL1077, IEC/EN 60947-2, and IEC/EN 60898-1, ensuring dependable operation and safety. Its IP20 and IP40 ratings protect against ingress and accidental contact, making it suitable for diverse environments.

Constructed with a delayed thermal tripping mechanism for overload and an electromechanical tripping mechanism for short circuits, the breaker provides precise, fast response to electrical faults. The anaerobic adhesive enhances the reliability of the tripping mechanism.

Dimensions of 88mm height, 70mm width, and 69mm depth allow for compact installation while maintaining robust protection capabilities. The operating ambient temperature ranges from -25°C to +55°C, with storage capability from -40°C to +70°C, making it versatile for various climates and industrial applications.

Manufactured in Germany, this product is part of ABB's commitment to sustainability, designed for disassembly and reuse, supporting environmental stewardship while providing cutting-edge electrical protection.

Offers a breaking capacity of 6 kA at 440V AC for effective fault interruption. Designed for mounting on DIN rails, facilitating easy installation. Features a screw-type terminal for secure electrical connections. Rated for operation in ambient temperatures ranging from -25°C to +55°C.

Conforms to international standards UL1077, IEC/EN 60947-2, and IEC/EN 60898-1. Equipped with anaerobic adhesive tripping mechanism for precise protection. Compact dimensions optimize panel space (88mm x 70mm x 69mm). IP20 and IP40 protection ratings ensure safety from contact and ingress.

Produced with sustainability focus, designed for disassembly.

This Miniature Circuit Breaker is suitable for use in industrial, commercial, residential, HVAC, and electrical panel applications, providing robust and reliable overcurrent protection. Explore more electrical circuit protection solutions and ABB brand products on EnvMart.
