ABB System Pro M Compact S200 Miniature Circuit Breaker 4-Pole 3A Type C 400V AC 440V DC 6 2CDS254001R0034 S204 C 3A - 10 KA

ABB 2CDS254001R0034 S204 C 3A - 10 KA System Pro M Compact S200 Miniature Circuit Breaker is a high-quality electrical protection device designed to safely interrupt overload and short circuit faults in electrical installations. With a 4-pole configuration and rated current of 3A, it supports reliable operation in various industrial and commercial applications.

This miniature circuit breaker features a type C tripping characteristic suitable for general-purpose circuits and moderate inrush currents. It can handle rated AC voltage of 400V and DC voltage up to 440V, making it versatile for AC and DC systems. The breaking capacity of 6 kA at 230/400 V AC ensures effective fault interruption to protect wiring and connected equipment from damage.

The device incorporates an electromechanic tripping mechanism with anaerobic adhesive to enhance operational durability and safety. It is designed to be mounted on a DIN rail with screw-type terminals for secure connections. Its compact dimensions - 88 mm in height, 70 mm in width, and 69 mm in depth - allow for efficient use of panel space.

Compliant with stringent international standards UL1077, IEC/EN 60947-2, and IEC/EN 60898-1, this circuit breaker guarantees consistent performance and safety. The IP20 rating provides protection against solid objects greater than 12 mm, suitable for typical electrical panels. It operates reliably in ambient temperatures ranging from -25 to +55 °C and can be stored safely between -40 and +70 °C.

As a Better World product designed for disassembly, it supports sustainable practices by facilitating responsible recycling and component reuse. Manufactured in Germany, the product reflects high engineering standards and quality assurance.

Ideal for use in industrial automation, electrical distribution systems, and commercial electrical panels, this ABB Miniature Circuit Breaker offers dependable protection and ease of installation. Choose the ABB System Pro M Compact S200 MCB for your electrical safety needs.

Designed for DIN rail mounting with screw terminal type connections. Operates at rated AC voltage of 400V and DC voltage of 440V. Electromechanic and thermal tripping mechanisms ensure reliable protection. Compact build with IP20 protection rating for electrical safety.

Conforms to major global standards for circuit breakers. Supports ambient operating temperatures between -25 to +55 °C. Better World certified with sustainability design principles. Compact dimensions optimize panel space usability.

4-pole configuration capable of multi-circuit breakdown protection. Made in Germany, ensuring quality and reliability. Explore more ABB circuit breakers and electrical protection devices with EnvMart for industrial and commercial applications.
