ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 3A Type K 440V AC 110V DC 6 kA Breaking 2CDS253103R0317

Free Delivery in India | Lowest Global Shipping Charges

ABB System Pro M Compact S200 Miniature Circuit Breaker 3+N-Pole 3A Type K 440V AC 110V DC 6 kA Breaking 2CDS253103R0317



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Germany
Range	System Pro M Compact
Brand	ABB
Height	88mm
Model	2CDS253103R0317
Depth	69mm
IP Rating	IP20, IP40
Width	70mm
Mount Type	DIN Rail
Current Rating	3A
Series	S200
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	3+N
Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2, UL1077
Rated AC Voltage	440V ac
Rated DC Voltage	110V dc
Tripping Characteristics	Type K
Better World Claim	Designed for Disassembly
Tripping Mechanism	Anaerobic Adhesive, Electromechanic

Key Features

Provides reliable overload and short circuit protection with dual tripping mechanisms.
Features Type K tripping characteristics for selective circuit protection.
Constructed for easy DIN rail mounting and screw terminal connection.
High breaking capacity of 6 kiloamperes ensures robust safety performance.
IP20 and IP40 rated for protection against solid objects and limited ingress.
Designed with environmentally conscious materials ensuring easy disassembly.
Compliant with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 standards.
Operable in ambient temperatures ranging from -25 to +55 °C.

Product Description

ABB 2CDS253103R0317 Miniature Circuit Breaker from the System Pro M Compact S200 series is engineered for reliable electrical protection in industrial, commercial, and residential installations. This 3+N-pole device has a current rating of 3A and offers Type K tripping characteristics which provide delayed tripping for overload protection and fast tripping for short circuits, combining thermal and electromechanical mechanisms.

The breaker supports rated voltages of 440V AC and 110V DC, ensuring versatile applicability in alternating and direct current systems. Its compact dimensions (70mm width, 88mm height, 69mm depth) make it suitable for space-constrained electrical panels and distribution boards.

Equipped with screw terminals and designed for DIN rail mounting, installation is straightforward. The device also features IP20 and IP40 protection ratings, guarding against accidental contact and solid particle ingress, enhancing operator safety and equipment reliability.

With a substantial breaking capacity of 6 kA, this breaker provides robust short-circuit interruption capability to protect wiring and downstream components. Built under stringent standards IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, the breaker assures compliance and quality assurance in electrical safety.

Further, the product is part of ABB's Better World initiative, designed for disassembly and environmental responsibility, reflecting sustainable manufacturing practices. Operational ambient temperatures range from -25 °C to +55 °C, allowing diverse environmental deployments.

Reliable dual thermal and electromechanical tripping mechanism for safety. DIN rail mounting and screw terminal for easy wiring and installation. Compact size enables use in limited space applications. Rated for both AC and DC voltage systems.

High breaking capacity for effective fault interruption. IP20/IP40 rating for safe operation and protection against solid ingress. Complies with multiple international electrical standards. Environmentally friendly design under ABB Better World program.

This Miniature Circuit Breaker is ideal for electrical distribution systems requiring dependable overload and short-circuit protection across industrial and commercial applications. Explore ABB products and System Pro M Compact range on EnvMart for dependable electrical protection solutions.
