Lovato Electric Miniature Circuit Breaker, 1-Pole, 20A, Type C, 400V AC, 60V DC, 10 kA Breaking Capacity P1MB

Lovato Electric P1MB miniature circuit breaker is a high-quality 1-pole protective device rated at 20 amperes, designed for both AC and DC electrical systems. It operates at a rated AC voltage of 400 volts and a DC voltage of 60 volts, suitable for residential, commercial, and light industrial electrical panels. Featuring a type C tripping characteristic, this breaker offers instantaneous thermal magnetic protection, ensuring quick disconnection in overload and short-circuit conditions to safeguard electrical circuits and connected equipment.

The breaker boasts a breaking capacity of 10 kiloamperes, providing a robust safety margin for a wide range of applications. Its form factor measures 76mm in width with 116mm depth and height, making it compact and ideal for DIN rail mounting, facilitating easy and secure installation in distribution boards.

Constructed to meet multiple international standards including IEC/EN/BS 60947-2, UL 489, cULus, and EAC, the P1MB series from Lovato Electric ensures compliance with global safety and performance benchmarks. The unit also features an IP20 protection rating, offering basic protection against accidental contact and ingress of solid objects.

This Miniature Circuit Breaker is utilized in industrial, commercial, and residential electrical distribution systems to protect wiring and equipment from overloads and short circuits. Its thermal magnetic tripping mechanism delivers precise and reliable operation, enhancing system safety and stability.

Key product attributes include current rating of 20 amperes, type C tripping characteristic, and compatibility with standard DIN rail mounting. The compact dimensions and high breaking capacity make it versatile for various electrical installation requirements.

Rated for 400V AC and 60V DC voltage operation. Breaking capacity of 10 kA ensures reliable circuit protection. Instantaneous thermal magnetic trip mechanism for rapid response. DIN rail mounting supports easy integration into switchboards.

IP20 rated for protection against solid object ingress. Standards-compliant with IEC/EN/BS 60947-2, UL 489, and others. Compact design with 76mm width, 116mm depth, and 116mm height. Explore other Lovato Electric circuit breakers and accessories in the Electronics & Electricals category at EnvMart for comprehensive electrical protection solutions.
