Mersen 315A Bolted Tag Fuse B4 690V AC, 111 mm K1006627 / BTMF69V315

Mersen model K1006627 / BTMF69V315 is a bolted tag fuse designed for robust electrical protection, rated at 315A and 690V AC. This B4 size fuse provides general-purpose and motor protection (gG and gM types), delivering excellent current limitation across a range of industrial and commercial applications.

This fuse adheres to international standards including EN 60269-2 and satisfies environmental regulations with RoHS, CE, and REACH compliance. It features a fuse speed rating of F, facilitating fast response to overload and fault currents.

Its mechanical specifications include 111 mm fixing centres and a 26 mm tag width, enabling secure installation either by screwing into fuse holders or bolting directly onto busbars or fuse disconnectors. The tag orientation is centred for stability during operation. This product is characterized by a compact design with 75 mm length, 138 mm overall length, and a 75 mm height, complemented by a 59.1 mm diameter and width.

The fuse is part of the Central Bolted Tag Fuse-links series gG 690VAC/460VDC and does not feature high rupture capacity, aligning it with general industrial power distribution requirements.

Manufactured in India, this fuse is built to ensure reliability, safety, and durability in electrical infrastructure applications including industrial, manufacturing, commercial, and transportation sectors.

This fuse features a current rating of 315A for high-load protection. It conforms to EN 60269-2 standards and is RoHS, CE, and REACH compliant. The fuse speed is type F, suitable for fast-acting applications. Dimensions include 111 mm fixing centres with a 26 mm tag width for installation compatibility.

It has a centred tag orientation ensuring stable mounting on fuseholders or busbars. The product is designed without high rupture capacity, optimized for standard protection needs. Its compact form factor includes 75 mm length, 138 mm overall length, 75 mm height, and 59.1 mm diameter and width.

Manufactured in India, ensuring local quality standards adherence. Explore our full range of electrical fusing solutions at EnvMart for optimal circuit protection tailored to your industrial and commercial needs.
