Gefran Solid State Relay Panel Mount, 60 A Load, 480 V AC Load, 32 V Control F084183/ GRS-H-60-48-D-1-0-0-0

Gefran F084183/ GRS-H-60-48-D-1-0-0-0 is a panel mount Solid State Relay designed for single-phase power control with a maximum load current rating of 60 A and a load voltage range up to 480 V AC. This relay is engineered for controlling resistive loads such as electrical heating elements precisely, making it ideal for industrial heating and automation applications.

Equipped with push-in type terminals and a mounting configuration suited for panel installation, the relay ensures reliable and easy connectivity in electrical control panels. It supports control input voltages ranging from 6 V to 32 V DC, accommodating various control systems.

The GRS-H series relay employs a zero cross switching mechanism that minimizes electrical noise during switching, enhancing safe and smooth operation. The relay features a 2CO (SPDT) contact configuration and utilizes MOSFET and Triac output technologies which provide stable and effective switching performance.

Operating reliably within the temperature range of 0°C to 80°C, this solid state relay complies with CE marking and European standards EN 61000-6-2, EN 61000-6-4, and EN 61010-1, ensuring quality and safety compliance. The off-state leakage current is minimal at 3 mA, reflecting energy efficiency during standby conditions.

Manufactured in Italy, the Gefran GRS-H relay is crafted to meet stringent industrial demands. Its compact dimensions (4.35 in height, 0.9 in width, 4.3 in depth) and integral heat sink design facilitate compact panel integration with enhanced thermal management for durability and performance.

This solid state relay is well-suited for a wide range of industrial, manufacturing, HVAC, and process control applications requiring precise and efficient resistive load management.

Capable of controlling resistive loads effectively in industrial heating applications. Panel mount type with push-in terminal connections for easy installation. Compatible with load voltages between 24 V AC minimum and 480 V AC maximum.

Input control voltage range from 6 V to 32 V DC for versatile control signal options. Features zero cross switching function to reduce electrical noise. Built to operate between 0°C and 80°C ambient temperature conditions.

Uses MOSFET and Triac output types ensuring reliable switching performance. Designed with 2CO (SPDT) contact configuration for improved control flexibility. Conforms to CE and relevant EN standards for operational safety and quality.

Manufactured in Italy with high standards of quality control. Explore more Solid State Relays and related automation components from top industrial brands at EnvMart for your panel control and power switching needs.
