Siemens SINAMICS G115D Series Inverter Drive, 370 W Power Rating, 3 Phase, 480V Supply, 2.6 A Max Output 6SL3520-3XE40-3AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-3XE40-3AF0 |
| IP Rating | IP65, IP66 |
| Mount Type | Panel |
| Series | SINAMICS G115D |
| Overall Width | 380mm |
| Power Rating | 370W |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 2.6A |
| Standards/Approvals | EAC, CE, KCC, REACH, SEMI F47, C-Tick (RCM) |
| Maximum Supply Voltage | 480V |
| Overall Depth | 129mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
Key Features
- The SINAMICS G115D series offers a fully preconfigured, modular frequency converter solution.
- Supports SIMOGEAR 2KJ8 geared motors including asynchronous IE3 and synchronous reluctance IE4 efficiency classes.
- Designed for robust panel mounting with IP65 and IP66 ingress protection ratings.
- Operates in extreme temperatures from -30°C up to 55°C.
- Provides integrated safety features including STO function with fail-safe digital input or PROFIsafe.
- Enables encoderless vector control for sophisticated horizontal conveyor applications.
- User-friendly modular design requires no control cabinet, saving space and reducing cooling needs.
- Conforms to multiple international standards including EAC, CE, KCC, REACH, SEMI F47, and C-Tick (RCM).
Product Description
Siemens 6SL3520-3XE40-3AF0 is a high-performance inverter drive from the SINAMICS G115D series, rated at 370 W power and designed for 3 phase electrical systems operating at up to 480V. This frequency converter supports SIMOGEAR 2KJ8 geared motors, accommodating both asynchronous motors with IE3 efficiency and synchronous reluctance motors with IE4 class, making it ideal for a wide range of industrial automation and conveyor system applications.
The drive features a compact panel mount design with IP65 and IP66 protection ratings, ensuring durability and resistance to dust and water ingress, suitable for demanding environments. It is capable of operating in wide temperature ranges from -30°C to 55°C, enhancing reliability under harsh conditions.
Equipped with advanced integrated safety features such as Safe Torque Off (STO) via fail-safe digital inputs or PROFIsafe communication, it ensures operational safety during installation and maintenance. The unit supports encoderless vector control, enabling precise speed regulation without additional motor feedback devices.
This modular and user-friendly system eliminates the need for a control cabinet, thereby reducing installation space and lowering cooling requirements, which simplifies the commissioning process and maintenance efforts.
Compliance with international standards like EAC, CE, KCC, REACH, SEMI F47, and C-Tick (RCM) confirms the product's quality and safety credentials. It is manufactured in the United Kingdom with a focus on energy efficiency and sustainability, underlining Siemens' commitment to environmentally responsible technology.
The SINAMICS G115D inverter drive supports motors with high efficiency classes IE3 and IE4. Its design facilitates easy installation, cabling, and commissioning for industrial conveyor systems. The drive's robust panel mount with IP66 protection suits harsh industrial conditions.
Wide operating temperature range enhances adaptability to diverse environments. Integrated safety functions promote operator and machine protection. Modular solution reduces need for external control cabinets. Meets multiple international compliance and quality standards.
Energy savings and sustainability are at the core of the product design. Ideal for horizontal conveyor systems requiring precise speed control. Explore more Inverter Drives and automation solutions from Siemens and other top brands at EnvMart to enhance your industrial setups with efficiency and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this inverter drive is 370 W.
The maximum output current is 2.6 A.
It has IP65 and IP66 ingress protection ratings, providing resistance to dust and water ingress.
This model operates in temperatures ranging from -30°C to 55°C.
It supports SIMOGEAR 2KJ8 geared motors, including asynchronous IE3 and synchronous reluctance IE4 efficiency classes.
The maximum supply voltage is 480 V.
The overall width is 380 mm and the overall depth is 129 mm.
It includes Safe Torque Off (STO) functionality via fail-safe digital inputs or PROFIsafe communication for enhanced safety.
No, it has a modular design that eliminates the need for a control cabinet, simplifying installation and reducing space requirements.
It conforms to several international standards including EAC, CE, KCC, REACH, SEMI F47, and C-Tick (RCM).
The output frequency is up to 550 Hz.
It is manufactured in the United Kingdom.
