Power Integrations Link Switch 170A 8-Pin SO-8C Flyback Power Management IC LNK3314D-TL
Specifications
| Country of Origin | India |
|---|---|
| Brand | Power Integrations |
| Height | 3.9mm |
| Length | 4.9mm |
| Model | LNK3314D-TL |
| Width | 1.75mm |
| Output Power | 10W |
| Mount Type | Surface |
| Maximum Duty Cycle | 69% |
| Series | LinkSwitch-TNZ |
| Topology | Flyback |
| Maximum Operating Temperature | 150°C |
| Package Type | SO-8C |
| Minimum Operating Temperature | -40°C |
| Switching Frequency | 66kHz |
| Maximum Input Voltage | 70V |
| Maximum Output Current | 170A |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 85V |
| Pin Count | 8 |
| Supply Current | 180μA |
| Minimum Output Current | 120mA |
Key Features
- Features a 725 V power MOSFET integrated onto the monolithic IC.
- Supports lossless generation of AC zero crossing signal for system clock and timing functions.
- Operates with a switching frequency of 66 kHz to reduce EMI filter complexity.
- Includes hysteretic thermal shutdown and soft-start to limit component stress during startup.
- Provides fast current limit and overvoltage protection circuitry for input and output.
- Operates over a temperature range of -40°C to 150°C ensuring robust performance.
- Compact SO-8C package with dimensions approximately 4.9 mm x 3.9 mm x 1.75 mm.
Product Description
Power Integrations LNK3314D-TL Link Switch is a highly integrated Flyback topology power management IC designed for efficient AC-DC conversion with 10W output power capacity and a maximum output current of 170A. This 8-pin SO-8C surface mount device incorporates a 725 V power MOSFET, oscillator, and multiple protection features onto a single chip.
The device supports lossless zero crossing signal generation which is typically used for system clock and timing applications. Its frequency jittering capability reduces EMI filter requirements, simplifying system design.
Additional features such as soft-start limit system component stress during power-up, while hysteretic thermal shutdown provides robust protection against overheating. Fast current limit and input/output overvoltage protection enhance reliability and operational safety.
Designed for industrial, electronic, and power management applications, the LNK3314D-TL performs reliably over a temperature range from -40°C to 150°C, suitable for demanding electronic components and power conversion environments.
The compact SO-8C package dimensions are 4.9 mm in length, 3.9 mm in height, and 1.75 mm in width, allowing for efficient PCB layout and assembly. Features a built-in 725 V MOSFET for power conversion efficiency. Generates lossless AC zero crossing signals for precise timing applications.
Uses a Flyback topology for power supply design flexibility. Includes hysteretic thermal protection and fast current limiting. Operates within wide temperature range for industrial use. Compact surface mount 8-pin SO-8C package for convenient PCB integration.
Suitable for power conversion in electronic devices, industrial automation, and power supply designs, this Link Switch IC integrates multiple functions to reduce component count and simplify system design. Explore more products in the Power Management IC category on EnvMart for your industrial and electronic system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LNK3314D-TL has an output power capacity of 10W.
It supports a maximum output current of 170A.
This model operates with a switching frequency of 66 kHz.
It operates over a temperature range of -40°C to 150°C.
The dimensions of the SO-8C package are approximately 4.9 mm in length, 3.9 mm in height, and 1.75 mm in width.
This power management IC uses a Flyback topology for power supply design flexibility.
It requires a minimum input voltage of 85V and a maximum input voltage of 70V.
It includes hysteretic thermal shutdown, soft-start, fast current limit, and overvoltage protection circuitry.
The supply current for this model is 180μA.
Yes, it has RoHS compliance as one of its standards/approvals.
This model uses surface mounting for installation.
It is designed for industrial, electronic, and power management applications, particularly for efficient AC-DC conversion.
