Vishay 45 V 3 A Surface Mount Schottky Rectifier Diode DO-221AC VSSAF3L45HM3_A/H

Free Delivery in India | Lowest Global Shipping Charges

Vishay 45 V 3 A Surface Mount Schottky Rectifier Diode DO-221AC VSSAF3L45HM3_A/H

Name: Vishay 45 V 3 A Surface Mount Schottky Rectifier Diode DO-221AC VSSAF3L45HM3_A/H
Brand: Vishay
SKU: 290744
Price: 0.24 USD
Availability: InStock



Category Schottky Diode Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	1mm
Length	5.35mm
Model	VSSAF3L45HM3_A/H
Width	2.7mm
Mount Type	Surface
Series	VSSAF3L45
Maximum Operating Temperature	150°C
Package Type	DO-221AC
Minimum Operating Temperature	-40°C
Standards/Approvals	AEC-Q101, JESD 201 Class 2 whisker test, UL 94 V-0, RoHS
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	3A
Peak Reverse Repetitive Voltage Vrrm	45V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	450μA
Peak Non-Repetitive Forward Surge Current Ifsm	80A
Maximum Forward Voltage Vf	0.54V

Key Features

Utilizes trench MOS Schottky technology for low forward voltage drop.
High efficiency and low power loss operation suitable for automated PCB assembly.
Compact DO-221AC package with dimensions 5.35 mm length, 2.7 mm width, 1 mm height.
Operates reliably between -40°C and 150°C with peak forward surge current up to 80 A.
Complies with AEC-Q101, JESD 201 Class 2 whisker test, UL 94 V-0 flammability, and RoHS standards.
Designed for use in low voltage, high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection in industrial and automotive applications.

Product Description

Vishay VSSAF3L45HM3_A/H is a high-performance surface mount Schottky rectifier diode rated for a maximum continuous forward current of 3 A and a peak reverse voltage of 45 V. Packaged in a compact DO-221AC form factor with a low profile height of 1 mm, it is ideal for automated placement in mass production environments.

This device features trench MOS Schottky technology which ensures a very low forward voltage drop of 0.54 V, enabling high efficiency operation with reduced power losses. Its thermal and electrical specifications support continuous operation in harsh environments with ambient temperatures from -40°C up to 150°C and a peak non-repetitive forward surge current of 80 A.

The diode meets rigorous automotive standard AEC-Q101 certification and is compliant with industry test standards including JESD 201 Class 2 whisker testing and UL 94 V-0 flammability rating. Additionally, it conforms to RoHS directives, making it suitable for environmentally conscious electronic designs.

Common applications include use as a freewheeling diode in power converters, polarity protection device in automotive circuits, and in low voltage high-frequency inverter topologies. Its compact size and surface mount footprint facilitate integration in high density and automated assembly production lines.

Set yourself for success in industrial, automotive, and commercial electronic manufacturing with the Vishay VSSAF3L45HM3_A/H Schottky rectifier diode. Utilizes trench MOS Schottky technology for low forward voltage drop.

High efficiency and low power loss operation suitable for automated PCB assembly. Compact DO-221AC package with dimensions 5.35 mm length, 2.7 mm width, 1 mm height. Operates reliably between -40°C and 150°C with peak forward surge current up to 80 A.

Complies with AEC-Q101, JESD 201 Class 2 whisker test, UL 94 V-0 flammability, and RoHS standards. Designed for use in low voltage, high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection in industrial and automotive applications.

Explore more Schottky Diodes and rectifiers suitable for demanding industrial and automotive electronics at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum continuous forward current of this diode is 3 A.

This model has a peak reverse voltage rating of 45 V.

The dimensions of the DO-221AC package are 5.35 mm in length, 2.7 mm in width, and 1 mm in height.

It operates reliably between -40°C and 150°C.

The maximum forward voltage drop is 0.54 V.

The peak non-repetitive forward surge current rating is 80 A.

It complies with AEC-Q101, JESD 201 Class 2 whisker test, UL 94 V-0, and RoHS standards.

This model uses surface mounting.

It is designed for use in low voltage, high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection in industrial and automotive applications.

The peak reverse current is rated at 450 μA.

The trench MOS Schottky technology ensures a very low forward voltage drop, enabling high efficiency operation with reduced power losses.

The diode configuration is single.
