Infineon OptiMOS 5 N-Channel MOSFET & Diode, 205 A, 40 V Enhancement, 8-Pin TDSON BSC014N04LSTATMA1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Height | 1.2mm |
| Length | 5.35mm |
| Model | BSC014N04LSTATMA1 |
| Width | 6.1mm |
| Mount Type | Surface |
| Series | OptiMOS 5 |
| Maximum Operating Temperature | 175°C |
| Package Type | TDSON |
| Minimum Operating Temperature | -55°C |
| Pin Count | 8 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 205A |
| Maximum Drain Source Voltage Vds | 40V |
| Maximum Drain Source Resistance Rds | 1.4mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 115W |
| Typical Gate Charge Qg @ Vgs | 61nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1V |
Key Features
- The device supports a maximum continuous drain current of 205 amps.
- It features a maximum drain-source voltage of 40 volts.
- The MOSFET has a low Rds(on) resistance of 1.4 milliohms.
- Designed for surface mount with 8 pins in a TDSON package.
- Enhanced channel mode is of the enhancement type.
- Maximum power dissipation rating is 115 watts.
- Operates reliably in temperatures ranging from -55°C to 175°C.
- Typical gate charge at Vgs is 61 nanocoulombs.
Product Description
Infineon BSC014N04LSTATMA1 OptiMOS 5 N-Channel MOSFET & Diode delivers cutting-edge performance with a continuous drain current rating of 205 A and a drain-source voltage of 40 V.
This device in a compact 8-pin TDSON package incorporates the latest SuperSO8 packaging technology that enhances thermal performance, allowing operation up to 175°C junction temperature.
The MOSFET's low Rds(on) resistance of 1.4 milliohms ensures efficient conduction and minimizes power losses, making it ideal for high-efficiency applications. With a maximum power dissipation of 115 W, this component supports demanding power management tasks in telecom, motor drives, server systems, and general power electronics.
The 20 V gate-source voltage rating and 61 nC typical gate charge provide excellent switching performance, optimizing synchronous rectification and enhancing system reliability. The robust construction supports an operating temperature range from -55°C to 175°C, ensuring longevity and stable performance under harsh conditions.
The device supports a maximum continuous drain current of 205 amps. It features a maximum drain-source voltage of 40 volts. The MOSFET has a low Rds(on) resistance of 1.4 milliohms. Designed for surface mount with 8 pins in a TDSON package.
Enhanced channel mode is of the enhancement type. Maximum power dissipation rating is 115 watts. Operates reliably in temperatures ranging from -55°C to 175°C. Typical gate charge at Vgs is 61 nanocoulombs. Maximum gate-source voltage rating is 20 volts.
Forward diode voltage is 1 volt, suitable for synchronous rectification. Compact physical dimensions include length 5.35 mm, width 6.1 mm, and height 1.2 mm. This Infineon OptiMOS 5 product is suited for industrial, telecom, automotive, and server power applications requiring high power density, efficiency, and thermal robustness.
Explore more components and power semiconductor devices from Infineon and other leading brands on EnvMart for your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 205 amps.
This device features a maximum drain-source voltage of 40 volts.
The MOSFET has a low Rds(on) resistance of 1.4 milliohms.
The maximum power dissipation rating is 115 watts.
It operates reliably in temperatures ranging from -55°C to 175°C.
The dimensions are 5.35 mm in length, 6.1 mm in width, and 1.2 mm in height.
This model is designed in an 8-pin TDSON package.
The typical gate charge at Vgs is 61 nanocoulombs.
The maximum gate-source voltage rating is 20 volts.
This device is suited for industrial, telecom, automotive, and server power applications.
It has an N-channel type with enhancement mode.
The forward voltage is 1 volt, suitable for synchronous rectification.
