Vishay 600 V 60 A General Purpose Rectifier & Schottky Diode 3-Pin TO-247AD 2L VS-E5TX3006THN3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 10.51mm |
| Length | 29.27mm |
| Model | VS-E5TX3006THN3 |
| Width | 4.65mm |
| Mount Type | Through Hole |
| Series | VS-E5TX |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247AD 2L |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS and AEC-Q101, JESD 201 Class 2 whisker test |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 60A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 20μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 310A |
| Maximum Forward Voltage Vf | 2.1V |
Key Features
- This diode features a low forward voltage drop of 2.1 V for optimized conduction losses.
- It is housed in a durable 3-pin TO-247AD 2L through-hole package.
- The diode operates reliably between -55°C and 175°C junction temperatures.
- Peak non-repetitive forward surge current capacity is 310 A.
- AEC-Q101 qualified, making it suitable for automotive and industrial applications.
- Optimized for fast switching and low switching losses in high-frequency converters.
Product Description
Vishay VS-E5TX3006THN3 is a general purpose rectifier and Schottky diode designed for efficient and reliable power conversion in industrial and automotive electronic systems. With a maximum continuous forward current of 60 A and a peak reverse voltage rating of 600 V, this diode supports heavy-duty performance in demanding environments.
The diode is housed in a 3-pin TO-247AD 2L through-hole package that enables easy mounting and excellent thermal dissipation. It features a low forward voltage of 2.1 V that reduces conduction losses and enhances overall energy efficiency, making it ideal for use in soft switched and resonant converter circuits.
Capable of operating within a wide temperature range from -55°C to 175°C junction temperature, this diode ensures high reliability even under harsh thermal conditions. The device can handle peak forward surge currents up to 310 A, providing robustness against transient overloads.
Qualified to AEC-Q101 standards and passing the JESD 201 Class 2 whisker test, it is suitable for automotive on-board battery chargers and similar medium-frequency hard switching converter applications. Polyimide passivation further improves device durability.
Its compact form factor with precise dimensions (29.27 mm length × 10.51 mm height × 4.65 mm width) allows seamless integration into various power management designs, making it a preferred choice for industrial, automotive, HVAC, manufacturing, and electric vehicle systems.
This diode features a low forward voltage drop of 2.1 V for optimized conduction losses. It is housed in a durable 3-pin TO-247AD 2L through-hole package. The diode operates reliably between -55°C and 175°C junction temperatures.
Peak non-repetitive forward surge current capacity is 310 A. AEC-Q101 qualified, making it suitable for automotive and industrial applications. Optimized for fast switching and low switching losses in high-frequency converters.
Compact dimensions: 29.27 mm length, 10.51 mm height, and 4.65 mm width ensure easy board integration. Explore more power semiconductors and Schottky Diode products on EnvMart for your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 60 A.
This diode has a peak reverse voltage rating of 600 V.
The maximum forward voltage drop for this diode is 2.1 V.
The dimensions of the TO-247AD 2L package are 29.27 mm in length, 10.51 mm in height, and 4.65 mm in width.
The diode operates reliably between -55°C and 175°C junction temperatures.
The peak non-repetitive forward surge current capacity is 310 A.
Yes, it is AEC-Q101 qualified, making it suitable for automotive applications.
This model uses a through-hole mounting type.
It meets RoHS and AEC-Q101 standards and has passed the JESD 201 Class 2 whisker test.
The diode configuration is single.
The peak reverse current is 20 μA.
It is optimized for fast switching and low switching losses in high-frequency converters.
