Silicon Labs 3.6V WiFi Module IEEE 802.11 b/g/n Ultra Low Power Transceiver WFM200SS22XNN3

Free Delivery in India | Lowest Global Shipping Charges

Silicon Labs 3.6V WiFi Module IEEE 802.11 b/g/n Ultra Low Power Transceiver WFM200SS22XNN3

Name: Silicon Labs 3.6V WiFi Module IEEE 802.11 b/g/n Ultra Low Power Transceiver WFM200SS22XNN3
Brand: Silicon Labs
SKU: 284331
Price: 20.22 USD
Availability: InStock



Category Wi-Fi Modules Brand Silicon Labs Condition New

Specifications

Country of Origin	India
Frequency	2484MHz
Brand	Silicon Labs
Height	1.4mm
Length	6.5mm
Model	WFM200SS22XNN3
Width	6.5mm
Series	WFM200SS22XNN3
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Interface Type	SPI, SDIO
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	1.8V
Supported Protocols	IEEE 802.11 b/g/n
Supported Security Standards	WPA2, WPA
Receiving Supply Current	42.3mA
Transmitting Supply Current	99.4mA

Key Features

Supports IEEE 802.11 b/g/n wireless protocols for versatile connectivity.
Operates with a supply voltage range from 1.8V to 3.6V.
Integrated embedded antenna, crystal, and shield for compact design.
Interfaces with host controllers using SPI and SDIO protocols.
Offers output TX power up to +15.1 dBm for reliable signal transmission.
Supports WPA and WPA2 security standards for secure data communication.
Wide operating temperature range from -40°C to 85°C for industrial applications.
Low receiving supply current of 42.3 mA and transmitting current of 99.4 mA for energy efficiency.

Product Description

Silicon Labs WFM200SS22XNN3 is a highly integrated ultra low power WiFi transceiver module designed for applications requiring optimal radio frequency performance, secure end-to-end communication, and rapid time to market. The module supports the IEEE 802.11 b/g/n wireless protocols and comes with an embedded antenna, high frequency crystal, and protective shield within its compact 6.5 mm by 6.5 mm footprint and a 1.4 mm height profile.

This WiFi module efficiently communicates with Linux-based or RTOS-based host processors through SPI or SDIO interfaces, supporting both split MAC and full MAC architectures. It delivers robust output power of +15.1 dBm and excellent receiving sensitivity at -96.3 dBm. It also includes integrated switched antenna diversity for enhanced connection quality and reliability.

Designed for industrial, commercial, and embedded applications, the WFM200SS22XNN3 operates reliably within a temperature range of -40°C to +85°C. The low power consumption characteristics include a receiving current of 42.3 mA and transmitting current of 99.4 mA, making it ideal for battery-powered devices.

The module supports the WPA and WPA2 security standards to ensure secure wireless data transmission. Its compact size and embedded features simplify design integration, providing a fast, cost-effective solution suitable for networked devices, smart home products, industrial IoT, and other wireless communication implementations.

Supports IEEE 802.11 b/g/n wireless protocols for versatile connectivity. Operates with a supply voltage range from 1.8V to 3.6V. Integrated embedded antenna, crystal, and shield for compact design. Interfaces with host controllers using SPI and SDIO protocols.

Offers output TX power up to +15.1 dBm for reliable signal transmission. Supports WPA and WPA2 security standards for secure data communication. Wide operating temperature range from -40°C to 85°C for industrial applications.

Low receiving supply current of 42.3 mA and transmitting current of 99.4 mA for energy efficiency. Compact module size of 6.5 mm x 6.5 mm x 1.4 mm suitable for embedded systems. Explore the complete range of Wi-Fi Modules at EnvMart for reliable and feature-rich wireless communication components.
