Eaton Residual Current Device PKNM Series, 10A, 2-Pole, 30 mA Trip Sensitivity, Type C, 10 kA 236077 PKNM-10/1N/C/003-MW

Eaton 236077 PKNM-10/1N/C/003-MW is a high-quality Residual Current Device (RCD) designed for sensitive fault detection with a 10 ampere current rating and 2 poles. Operating at 230V AC, it features a 30 mA trip sensitivity and Type C tripping characteristic suitable for industrial and commercial electrical installations, providing vital protection against electrical shocks and fire hazards.

This residual current device incorporates a robust electromagnetic tripping mechanism and an instantaneous break time to ensure rapid disconnection under fault conditions. The device securely mounts on DIN rails and uses screw-type terminals for reliable electrical connections.

Measuring 80mm in height, 70mm in width, and 70.5mm in depth, it is compact enough for standard panel installations. The 10 kA breaking capacity ensures safe interruption of high fault currents. The reset actuator toggle switch provides an easy manual reset option after tripping.

Conforming to IEC/EN 61008 standards, this Eaton PKNM series device includes safety features such as red and green contact position indicators to denote operational status. It is ideal for industrial automation, electrical safety systems, manufacturing facilities, and commercial electrical wiring networks where protection against earth leakage currents is critical.

Designed for industrial use ensuring protection against electric shock hazards. Type C tripping characteristic providing instantaneous break action. Compact dimensions of 80mm height, 70mm width, and 70.5mm depth fit standard DIN rails.

Screw terminal type ensures secure and easy wiring connections. Breaking capacity of 10 kA at 230V AC for high fault current interruption. Equipped with toggle switch reset actuator for quick manual reset. Electromagnetic tripping mechanism provides precise fault detection.

Conforms to IEC/EN 61008 standards for safety and quality assurance.

This Eaton Residual Current Device is manufactured in Romania and is suitable for use in electrical panels requiring reliable and fast earth fault protection compliant with international standards. Browse more specialized electrical protection devices and circuit breakers at EnvMart.
