Simex 3 Digit LED Counter 13 mm Digit Height Automatic & Manual Reset SLN-94-1421-1-4-001

The Simex SLN-94-1421-1-4-001 is a robust and reliable 3 digit LED counter specifically engineered for up-down counting of pulses in industrial process control applications. It features a 13 mm high LED dual display providing excellent readability of threshold and current process values. The device supports both automatic and manual reset methods, allowing users to select the reset mode best suited for their application.

Equipped with a batch programming function, the SLN-94 counter offers two relay or open collector outputs for rough and accurate batching control, making it ideal for manufacturing, automation, and process monitoring environments. Installation is simplified through panel mounting with IP65 protection on the front panel when using the waterproof cover. Without the cover, the front panel is IP40 rated, while the housing and connection clips provide IP20 protection.

The counter can be programmed easily using three buttons beneath each decade on the green SV threshold value display. It features a programmable decimal point and a divider, enhancing flexibility for custom counting requirements. The built-in RS485 communication interface facilitates integration into industrial networks and automation systems.

Designed for use in harsh conditions, the counter meets CE standards and is manufactured in Poland, promising durability and compliance. It finds applications across industrial automation, process control, electrical control gear, and manufacturing industries.

3-digits (13 mm) LED dual display with clear SV and PV values. Supports up-down and down-up pulse counting with programmable activation threshold. Batching function with two relay or OC outputs for precise control. Panel mounting design with IP65 front protection when fitted with waterproof cover.

Four reset sources with programmable automatic reset option. Programmable divider and decimal point position for versatile configuration. Built-in RS485 communication port for network integration. CE certified and engineered for harsh environmental conditions.

Manufactured in Poland ensuring high-quality standards.

This counter is a valuable instrument for industries requiring accurate digital counting and batching solutions. Explore the full range of industrial automation and process control products on EnvMart for compatible control gear and Counters.
