SMC Pneumatic Solenoid Valve 5/2 Solenoid M5 Die Cast Zinc Body 24V DC 1W VQC1000

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Solenoid Valve 5/2 Solenoid M5 Die Cast Zinc Body 24V DC 1W VQC1000



Category Pneumatic Solenoid Valve Brand SMC Condition New

Specifications

Country of Origin	India
Voltage	24V dc
Brand	SMC
Body Material	Die Cast Zinc
Maximum Operating Pressure	0.7 Mpa
Height	93.5mm
Length	135.5mm
Model	VQC1000
Width	63.5mm
Mount Type	Base
Series	VQC1000
Number Of Ports	5
Maximum Operating Temperature	50°C
Port Type	Support, EXH, Cylinder
Number of Positions	2
Seal Material	Metal
Minimum Operating Temperature	-10°C
Actuation Type	Solenoid
Standards/Approvals	RoHS, CE
Connection Thread Standard	M5
Minimum Pilot Pressure	0.1MPa
Valve Function	5/2
Solenoid Type	Double
Port Gender	Female
Solenoid Power Consumption	1W

Key Features

Compact design suitable for various pneumatic systems.
Die cast zinc body ensures durability and corrosion resistance.
Operates at maximum pressure of 0.7 MPa with metal seal material.
Features fast response time and long life expectancy of up to 200 million cycles.
Supports base mount type with 5 ports and 2 valve positions.
Easy mounting using a single screw and clamp system.
Operating temperature range from -10°C to 50°C.
Complies with RoHS and CE standards ensuring quality and safety.

Product Description

SMC VQC1200N-51 Pneumatic Solenoid Valve 5/2 Solenoid M5 from the VQC1000 series operates at 24V DC with 1W power consumption, designed for fast and reliable pneumatic system control.

This valve features a compact and robust die cast zinc body construction with metal seals, enhancing durability and corrosion resistance, making it suitable for industrial, manufacturing, and automation applications.

The valve supports a maximum operating pressure of 0.7 MPa and offers a versatile 5-port configuration with 2 valve positions, providing efficient pneumatic flow control and switching.

Its operating temperature range of -10°C to 50°C enables deployment in various environmental conditions. The mounting is base type for quick installation and maintenance, facilitated by a single screw and clamp system.

The valve’s solenoid actuation is double type with a pilot pressure range from 0.1 MPa to 0.7 MPa. It complies with RoHS and CE certification standards, ensuring environmental compliance and quality assurance.

Compact design suitable for various pneumatic systems. Die cast zinc body ensures durability and corrosion resistance. Operates at maximum pressure of 0.7 MPa with metal seal material. Features fast response time and long life expectancy of up to 200 million cycles.

Supports base mount type with 5 ports and 2 valve positions. Easy mounting using a single screw and clamp system. Voltage rating of 24V DC with 1W solenoid power consumption. Operating temperature range from -10°C to 50°C.

Complies with RoHS and CE standards ensuring quality and safety. Port type includes support, exhaust (EXH), and cylinder connections with female port gender.

This solenoid valve is ideal for industrial, manufacturing, pneumatic automation, and fluid power applications, providing precise valve function and reliable operation. Explore more Pneumatic Solenoid Valves from SMC and related pneumatic valves on EnvMart.
