ABB System Pro M Compact S200 Miniature Circuit Breaker, 4-Pole, 50A, Type Z, 440V AC 2CDS254001R0578 S204 Z 50A - 10 KA

ABB 2CDS254001R0578 S204 Z 50A - 10 KA Miniature Circuit Breaker from the System Pro M Compact S200 series is engineered for industrial and commercial electrical circuit protection. It is a 4-pole device with a 50 ampere current rating, designed for reliable overload and short circuit protection in complex electrical systems. Its type Z tripping characteristics make it ideal for specific applications requiring precise trip settings.

This circuit breaker supports a rated AC voltage of 440V and a rated DC voltage of 110V, providing flexibility for a range of electrical installations. The device features a high breaking capacity of 20 kA, enabling it to clear faults effectively and safeguard electrical infrastructure.

The S200 series breaker mounts easily on DIN rails, facilitating quick installation and maintenance. Its compact design with dimensions of 88mm height, 70mm width, and 69mm depth allows efficient use of panel space. The IP20 and IP40 ingress protection ratings ensure the device can withstand dust and accidental contact in typical industrial environments.

Compliant with IEC/EN 60947-2 and UL1077 safety standards, this MCB guarantees high quality and safety. The unit uses an anaerobic adhesive tripping mechanism, offering enhanced reliability in operation. It performs reliably across ambient air temperatures ranging from -25 °C to +55 °C during operation and can be safely stored between -40 °C and +70 °C. Manufactured in Germany, this product embodies robust engineering and quality assurance.

4-pole design ensures comprehensive circuit breaking capabilities. Rated current of 50A suitable for medium load applications. Type Z tripping characteristics for specific circuit protection needs. Supports rated voltages of 440V AC and 110V DC for versatile usage.

Breaking capacity of 20 kA provides high fault clearing capability. DIN rail mounting type for easy and secure installation. Complies with IEC/EN 60947-2 and UL1077 standards ensuring safety and quality. Compact dimensions: 88mm height, 70mm width, and 69mm depth for space-saving designs.

IP20 and IP40 ingress protection ratings allowing suitable environmental use. Designed with anaerobic adhesive tripping mechanism for reliable operation. Operational ambient temperature range from -25 to +55 °C and storage from -40 to +70 °C.

This Miniature Circuit Breaker is suited for use in electrical panels, automation systems, and power distribution assemblies in industrial, commercial, and residential applications. Its robust design and certified safety features ensure effective protection of electrical circuits from overloads and short circuits. Explore additional ABB electrical products and circuit protection solutions at EnvMart for reliable and efficient power management.
