ABB System Pro M Compact S200 Miniature Circuit Breaker 4-Pole 500mA Type K 440V AC 110V 2CDS254001R0157 S204 K 0.5A - 10 KA

ABB 2CDS254001R0157 S204 K 0.5A - 10 KA Miniature Circuit Breaker is part of the System Pro M Compact S200 series designed for industrial, commercial, and automation electrical protection applications. It offers reliable protection with its dual tripping mechanisms, providing thermal overload and electromechanical short circuit protection.

This 4-pole Miniature Circuit Breaker is rated for 500mA current with Type K tripping characteristic, suitable for controlling and protecting sensitive electrical circuits. It supports up to 440V AC and 110V DC making it versatile for various electrical environments.

The high breaking capacity of 230kA ensures safety and protection against fault currents. It mounts on standard DIN rails and features screw terminal connections, facilitating easy installation and robust electrical contacts.

Compact in size with dimensions 70mm width, 88mm height, and 69mm depth, it fits efficiently within electrical panels where space is a premium. The IP20 rating provides protection against solid objects, enhancing operational safety.

Manufactured under stringent standards IEC/EN 60947-2 and UL 1077, it guarantees compliance with global quality and safety requirements. Additionally, it supports ABB's Better World sustainability claim as it is designed for disassembly, promoting recycling and environmental responsibility.

The device is operable within ambient air temperature ranges of -25 to +55 °C for operation and -40 to +70 °C for storage, ensuring functionality under diverse climatic conditions. This circuit breaker is made in Germany, reflecting high quality manufacturing processes.

Equipped with both delayed thermal and electromechanical tripping mechanisms for overload and short circuit protection. Rated for 440V AC and 110V DC operations ensuring versatile use. Breaking capacity of 230kA for high fault current interruption.

Mounts easily on DIN Rail with screw terminals for secure connections. Compact dimensions of 70mm width, 88mm height, and 69mm depth for space-efficient installations. Compliant with IEC/EN 60947-2 and UL 1077 standards for quality and safety.

IP20 rating providing protection against solid objects larger than 12 mm. Designed for disassembly supporting sustainability and recyclability. Operable in ambient temperatures from -25°C to +55°C, suitable for varied environments.

Manufactured in Germany ensuring high manufacturing standards. Explore EnvMart’s extensive selection of circuit breakers and electrical protection devices to find reliable solutions for your industrial and commercial needs.
