KEMET SPST Through Hole Reed Switch 300 mA 110 V AC/DC OHD3-55B

KEMET OHD3-55B SPST Through Hole Reed Switch is a high-reliability component designed for industrial and commercial applications requiring precise switching control. Rated at a maximum switching current of 300 mA and voltage of 110 V AC/DC, this reed switch is ideal for signal switching where compact size and durability are critical.

The switch utilizes a single pole single throw (SPST) contact configuration and employs nickel iron alloy contacts with a low contact resistance of 150 milliohms, ensuring minimal voltage drop and efficient conduction.

Its robust construction includes tab leads for through hole mounting on printed circuit boards, facilitating straightforward integration into electronic assemblies. Operating over a broad temperature range of -20°C to 150°C, the OHD3-55B reed switch can withstand challenging conditions encountered in various industrial environments.

The compact physical dimensions of 27 mm length, 13.5 mm width, and 12.5 mm depth make it suitable for applications with space constraints. This product complies with international standards including TUV, RoHS, UL, and CSA, reflecting adherence to rigorous safety and environmental requirements.

Typical applications include atmospheric temperature detection, overheating monitoring in power transistors, motors, amplifiers, and other general electronic appliances requiring sensitive switch actuation.

Manufactured in Japan, the OHD3-55B Reed Switch delivers dependable performance backed by stringent quality control. Set a high standard of reliability in your industrial, automation, or electronic device designs with this precise and durable switch.

The single pole single throw (SPST) contact configuration ensures reliable on/off switching. Maximum switching power is 6 watts, supporting low power control circuits efficiently. Contact resistance is low at 150 milliohms, providing excellent electrical conductivity.

Constructed with nickel iron alloy contact material for durability and corrosion resistance. Designed for through hole mounting with tab leads for easy PCB integration. Operating temperature range from -20°C to 150°C enables use in harsh environments.

Compact dimensions: length 27 mm, width 13.5 mm, depth 12.5 mm optimize space usage. Meets TUV, RoHS, UL, and CSA standards ensuring safety and quality compliance. Originated from Japan, guaranteeing high manufacturing standards.
