ABB Miniature Circuit Breaker, 1-Pole, 6A Current Rating, Type C Tripping Characteristic, 230V AC, 6 kA Breaking SN201

ABB SN201 Miniature Circuit Breaker is a high-quality electrical protection device featuring a single pole with a 6A current rating and Type C tripping characteristics. It operates at a rated AC voltage of 230V and offers a 6 kA breaking capacity, making it highly suitable for residential electrical panels, light commercial installations, and automation systems that require reliable short circuit interruption.

The compact design with dimensions of 85mm height, 85mm depth, and 18mm width allows this MCB to fit easily in space-constrained electrical distribution boards. The device utilizes screw-type terminals ensuring strong and dependable connections. It is designed for mounting on standard DIN rails, facilitating quick installation and maintenance.

Compliant with IEC/EN 60898-1 standards, this miniature circuit breaker ensures adherence to recognized safety and performance benchmarks. It features a Type C tripping characteristic ideal for circuits with moderate inrush currents, such as motor start-ups or lighting loads, providing reliable overload and short circuit protection.

The toggle switch reset actuator offers user-friendly manual control for resetting the breaker after tripping events. The 6 kA breaking capacity guarantees robust fault interruption capability, protecting electrical circuits and connected equipment efficiently.

Reliable short circuit protection enhances operational safety. Type C tripping characteristic supports applications with higher inrush currents. Screw terminal connections provide secure wiring stability. DIN rail mounting supports fast and standardized installation.

Compact form factor optimizes use of panel space. Compliance with IEC/EN 60898-1 confirms quality and safety. Toggle switch actuator enables easy manual reset after trips. 6 kA breaking capacity effectively handles fault currents.

This ABB SN201 Miniature Circuit Breaker is ideal for household electrical panels, small commercial systems, industrial automation applications, and motor circuit protection. It delivers dependable and compliant circuit protection performance tailored to current demands of modern electrical installations.
