ABB xEffect Miniature Circuit Breaker, 3 Pole, 16A, Type D Tripping, 415V AC, 60V DC, 10 kA Breaking 278896 FAZ-D16/3
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | ABB |
| Model | 278896 FAZ-D16/3 |
| Depth | 73mm |
| IP Rating | IP20 |
| Width | 85mm |
| Mount Type | DIN Rail |
| Current Rating | 16A |
| Series | xEffect |
| Terminal type | Twin-Purpose Terminal |
| Breaking Capacity | 10kA |
| Number of Poles | 3 |
| Rated AC Voltage | 415V ac |
| Rated DC Voltage | 60V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Rated for 415V AC and 60V DC operation.
- Breaking capacity of 10 kA ensures reliable protection.
- Features thermal magnetic tripping mechanism for instant break.
- Designed for DIN rail mounting with toggle switch reset actuator.
- Equipped with twin-purpose terminals for versatile wiring.
- IP20 protection rating suitable for indoor electrical panels.
- Red and green contact position indicators for clear status monitoring.
- Wide operating temperature range from -40°C to +75°C.
Product Description
Eaton 278896 FAZ-D16/3 miniature circuit breaker is a 3-pole electrical protection device designed for robust industrial, commercial, and manufacturing environments. It operates at a voltage rating of 415V AC and 60V DC with a current rating of 16A. The breaker utilizes thermal magnetic Type D tripping characteristics, which allows it to trip at currents 10 to 20 times the rated current, making it highly effective for protecting circuits prone to surge currents, such as welding equipment, X-ray machines, and uninterruptible power supplies.
This xEffect series MCB provides a breaking capacity of 10 kA, ensuring high interruption performance under fault conditions. The device features a toggle switch reset actuator and twin-purpose terminal connections for flexible wiring arrangements. It attaches easily to standard 35 mm DIN rails for quick installation and maintenance.
Additional features include red and green contact position indicators for ease of circuit status monitoring and an IP20 ingress protection rating, safeguarding against solid objects larger than 1 mm. The device also operates effectively over a broad temperature range from -40 to +75 degrees Celsius, making it suitable for use in challenging industrial environments.
For enhanced functionality, a field-installable shunt trip auxiliary switch (part number 922-6958) can be added after installation for remote tripping capability. Rated AC voltage: 415V AC. Rated DC voltage: 60V DC. Current rating: 16A.
Number of poles: 3. Breaking capacity: 10 kA. Tripping mechanism: Thermal magnetic, instantaneous break. Mount type: DIN rail. Reset actuator: Toggle switch. IP rating: IP20. Operating temperature range: -40°C to +75°C.
This Eaton miniature circuit breaker is ideal for use in electrical, automation, industrial manufacturing, and commercial power distribution applications, providing reliable overload and short circuit protection.
Explore the wide selection of Miniature Circuit Breakers and electrical protection devices available at EnvMart for comprehensive electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a rated AC voltage of 415V and a rated DC voltage of 60V.
The breaking capacity is 10 kA, ensuring reliable interruption performance under fault conditions.
This miniature circuit breaker features 3 poles.
It utilizes a thermal magnetic tripping mechanism with Type D characteristics, which allows it to trip at currents 10 to 20 times the rated current.
It operates effectively over a wide temperature range from -40°C to +75°C.
It is designed for DIN rail mounting, making installation straightforward.
The dimensions are 85mm in width and 73mm in depth.
It features a toggle switch reset actuator for easy operation.
It is equipped with twin-purpose terminals for versatile wiring arrangements.
Yes, it has an IP20 protection rating, suitable for indoor electrical panels.
It is ideal for electrical, automation, industrial manufacturing, and commercial power distribution applications.
Yes, a field-installable shunt trip auxiliary switch can be added for remote tripping capability.
