Eaton FRCdM Series Residual Current Circuit Breaker 63A 4-Pole 300 mA Type B Tripping 630A 167906 FRCDM-63/4/03-G/BFQ

Eaton 167906 FRCDM-63/4/03-G/BFQ is a high-performance Residual Current Circuit Breaker (RCCB) from the FRCdM series, designed to provide superior protection against electrical leakage faults in industrial applications.

This model features a 63A current rating and a 4-pole configuration, with a trip sensitivity of 300mA and type B tripping characteristic, capable of detecting AC pulsating and DC residual currents up to 1 kHz frequency, ensuring enhanced safety and equipment protection.

The breaker supports a rated breaking capacity of 630A and operates reliably at 220V DC and 240V AC voltages. Its electromagnetic tripping mechanism provides rapid fault interruption, reducing risk of electrical hazards.

Equipped with integrated auxiliary contact and local indication via three LEDs, the device allows for easy monitoring of operational status and fault conditions. The digital residual current detection also includes a preventive warning feature that alerts users before trips occur.

The product is suited for DIN rail mounting, allowing for straightforward installation in control panels and switchboards. With compact dimensions (80mm height, 76mm width, and 70.5mm depth), it fits efficiently within limited spaces.

The FRCdM range ensures compliance with international standards IEC 61373, IEC/EN 61008, and EN 45545-2, assuring quality and safety in demanding environments.

This advanced RCCB is ideal for industrial, manufacturing, electrical engineering, and renewable energy applications, offering dependable earth leakage protection and system monitoring capabilities.

Type B tripping characteristic sensitive to AC and DC residual currents up to 1 kHz. 300mA trip sensitivity for reliable earth leakage detection. Integrated auxiliary contact and LED local indication enhance system monitoring.

Electromagnetic tripping mechanism ensures rapid fault interruption. Rated breaking capacity of 630A at 220V DC / 240V AC operation. DIN rail mount for easy and secure installation. Compact dimensions suitable for various industrial control setups.

Complies with IEC 61373, IEC/EN 61008, and EN 45545-2 standards. Built-in digital features provide preventive warnings before trips. Explore the full range of Eaton Residual Current Circuit Breakers in the Electronics & Electricals category at EnvMart for enhanced electrical safety solutions.
