Eaton FRCdM Series Residual Current Circuit Breaker 40A 3-Pole 300 mA Type B 500A 220V dc 240V ac 167909 FRCDM-40/4/03-S/BFQ

Eaton 167909 FRCDM-40/4/03-S/BFQ Residual Current Circuit Breaker is a high-precision digital device designed to protect electrical systems in industrial environments. With a 40A current rating and 3 poles, it offers robust fault detection and protection capabilities. Its 300 mA trip sensitivity and Type B tripping characteristics make it suitable for detecting DC and AC leakage currents, preventing electrical hazards effectively.

This breaker supports DIN rail mounting, allowing easy integration into electrical panels and distribution boards. Its breaking capacity of 500A ensures it can handle high fault currents typical of industrial applications. Operating at up to 220V DC and 240V AC, it is versatile for various electrical systems.

Equipped with an electromagnetic tripping mechanism, the device provides fast and reliable fault clearing. Advanced system monitoring technology issues preventive warnings before a leakage trip occurs, enhancing operational safety and reliability.

The breaker includes local indication using three LEDs, providing clear visual status information. Screw-type terminals enable secure and stable connections. Compact dimensions of 80mm height, 70.5mm depth, and 76mm width allow for space-efficient installations.

Compliance with stringent standards such as EN 45545-2, IEC 61373, and IEC/EN 61008 ensures high safety, reliability, and performance quality. This product is ideal for industrial automation, electrical distribution, and safety systems requiring sensitive residual current protection.

Eaton, formerly known as Moeller, continues to deliver innovative circuit protection solutions with the FRCdM series, combining digital features and comprehensive fault monitoring. The breaker includes a real contact position indicator, fault current tripping indicator, and transparent designation plate.

Its design reduces unwanted tripping and eliminates the need for monthly testing, resulting in lower maintenance. This series also offers a comprehensive range of accessories to customize installations according to specific industrial requirements.

Explore more circuit protection devices and accessories from Eaton in the Electronics & Electricals category on EnvMart. Equipped with Type B tripping characteristics for DC and AC leakage detection. Designed for industrial electrical safety and fault protection.

Compliant with multiple international electrical safety standards.
