Legrand Residual Current Circuit Breaker with Overcurrent Protection 20A 1-Pole 30mA Trip 236965 PXK-C20/1N/003-A

Free Delivery in India | Lowest Global Shipping Charges

Legrand Residual Current Circuit Breaker with Overcurrent Protection 20A 1-Pole 30mA Trip 236965 PXK-C20/1N/003-A

Name: Legrand Residual Current Circuit Breaker with Overcurrent Protection 20A 1-Pole 30mA Trip 236965 PXK-C20/1N/003-A
Brand: Legrand
SKU: 254491
Price: 8993.91 INR
Availability: InStock



Category Residual Current Circuit Breaker Brand Legrand Condition New

Specifications

Country of Origin	Austria
Range	PXK
Brand	Legrand
Model	236965 PXK-C20/1N/003-A
Depth	69.5mm
Current Rating	20A
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	IEC/EN 61009
Rated AC Voltage	240V ac
Tripping Characteristics	Type C
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A

Key Features

Combines RCD and MCB functionalities to protect against earth faults, overloads, and short circuits.
Features a Type C tripping characteristic suitable for commercial and industrial applications.
Robust UV-protected casing safeguards against damage from direct sunlight.
Quick trip sensitivity of 30mA reduces risk of prolonged electric shocks.
Ingress protection rating IP20 prevents contact with open wires and corrosion.
Compact depth of 69.5mm enables easy panel installation.
High breaking capacity of 10kA ensures effective fault current interruption.
Certified to IEC/EN 61009 standards for quality and safety.

Product Description

Eaton 236965 PXK-C20/1N/003-A Residual Current Circuit Breaker with Overcurrent Protection offers combined residual current detection and miniature circuit breaking in a single compact device. Rated for 20A current and sensitive to 30mA trip, it enhances operator safety and equipment reliability by quickly disconnecting power during earth faults and overloads.

This RCBO features a Type C tripping characteristic, allowing it to withstand between five and ten times its rated current before tripping, making it ideal for industrial and commercial electrical installations requiring higher inrush currents.

The device casing is UV-protected ensuring durability and resistance to sunlight-induced degradation, suitable for varied installation environments. With an ingress protection rating of IP20, it effectively prevents accidental contact with live parts and ingress of corrosive particles.

Additional benefits include a compact design with a depth of 69.5mm, enabling space-efficient panel integration. It also boasts a breaking capacity of 10kA, providing robust fault interruption capability compliant with IEC/EN 61009 standards.

Its application scope covers residential, commercial, and light industrial settings where reliable earth leakage and overcurrent protection is vital. The unit trips both live and neutral circuits, minimizing risk for personnel and equipment damage.

Combines residual current and overcurrent protection functionalities. High trip sensitivity of 30mA reduces electric shock risk. Type C tripping characteristic supports commercial usage. UV-protected casing enhances device lifespan.

Compact 69.5mm depth suits panel mounting. Breaking capacity of 10kA meets stringent safety standards. IP20 protection against accidental contact and moisture. Conforms to IEC/EN 61009 safety standards. Manufactured in Austria ensuring quality assurance.

This Eaton Residual Current Circuit Breaker is essential for industrial, commercial, and residential electrical safety protection applications. Browse more premium circuit breakers and related electrical products on EnvMart.
