Lovato Electric Modulo P1MB Miniature Circuit Breaker 1-Pole 20A Type C 230V AC 60V DC 10 kA Breaking P1MB

Lovato Electric P1MB miniature circuit breaker is a high-quality 1-pole breaker rated at 20 amperes, designed for both AC and DC circuits with voltages of 230V AC and 60V DC respectively. It features a Type C tripping characteristic, which is ideal for protecting circuits with moderate inrush currents such as lighting and small motor loads.

The breaker is engineered for DIN rail mounting, facilitating easy and secure installation in electrical distribution panels. Its robust thermal magnetic tripping mechanism provides accurate response to overload and short-circuit conditions, enhancing electrical safety.

With compact dimensions of 18mm width, 86.5mm height, and 80mm depth, this breaker fits efficiently within standard switchgear cabinets without consuming excessive space. The high breaking capacity of 10 kA allows it to safely interrupt large fault currents, minimizing damage to electrical infrastructure.

The device is rated IP20, offering protection against access to hazardous parts and solid objects, making it suitable for indoor electrical installations. It complies with stringent international standards like IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, CSA, cURus, EAC, and UL 1077, ensuring reliable performance and safety compliance.

Applications of this MCB include residential homes, commercial buildings, and light industrial setups where circuit protection and prevention of electrical faults are critical. The positive indication flag window clearly shows the switching status, enabling quick identification of tripped conditions.

Designed for DIN rail mounting for easy installation. Features thermal magnetic tripping mechanism ensuring reliable protection. Compact dimensions: 18mm width, 86.5mm height, and 80mm depth. Breaking capacity of 10 kA enables safe interruption of short-circuit currents.

IP20 rated for basic protection against solid ingress. Complies with multiple international standards including IEC/EN/BS 60898-1 and UL 1077. Positive indication by flag window for clear operational status. Suitable for residential, commercial, and industrial electrical protection.

This miniature circuit breaker is part of Lovato’s Modulo series, recognized for high quality and dependable circuit protection solutions. Browse more Miniature Circuit Breakers and related electrical components on EnvMart for your industrial and commercial needs.
