Theben Digital DIN Rail Time Switch 230V ac Astronomical Weekly Program 56 Memory Spaces SELEKTA 170 Top3

Theben SELEKTA 170 Top3 is a premium digital DIN rail time switch designed for precise timing and control in industrial automation, process control, and electrical installations. This model offers a single channel with a single pole double throw (SPDT) contact, accommodating sophisticated weekly programming with 56 memory spaces and an astronomical timing function based on sunrise and sunset times.

Operating at 230V AC with a frequency range of 50Hz to 60Hz, the SELEKTA 170 Top3 is suitable for a wide range of industrial and commercial applications requiring reliable automated control.

The robust housing is built from highly temperature-resistant and self-extinguishing thermoplastic, enhancing durability and safety. It features DuoFix spring terminals which facilitate secure and efficient wiring installation.

Programming flexibility is enhanced with Bluetooth low energy OBELISK top3 functionality, allowing secure transfer and manipulation of timing programs via an app. This ensures maximum security as manipulation of switching times is only possible with the OBELISK connected.

Additional features include a 10-year battery life to maintain memory integrity, fixed ON/OFF switching capability, and simulation of switching times for testing purposes. The device operates reliably in ambient temperatures ranging from -30°C to +55°C, making it suitable for diverse industrial and commercial environments.

Single channel digital time switch with SPDT contact configuration. Advanced astronomical timing with weekly programming and 56 memory spaces. 10-year battery life ensures data retention over long periods. Bluetooth OBELISK top3 support for secure programming via app.

Durable thermoplastic housing with high temperature resistance and self-extinguishing properties. Operating temperature range: -30°C to +55°C for versatile environmental conditions. DuoFix spring terminals for secure and easy connection.

IP20 protection rating for indoor use. Ideal for industrial automation, process control, HVAC systems, and building automation.

This Theben SELEKTA 170 Top3 digital DIN rail time switch is manufactured in Germany, reflecting high quality and engineering standards. It suits applications including industrial automation systems, electrical control panels, building management systems, and time-based control of lighting and machinery.
