Siemens SENTRON Miniature Circuit Breaker, 1-Pole, 10A, Type D, 400V AC, 60V DC, 10 kA Breaking Capacity 5SY4110-8
Specifications
| Country of Origin | Germany |
|---|---|
| Range | SENTRON |
| Brand | Siemens |
| Height | 90mm |
| Model | 5SY4110-8 |
| Depth | 76mm |
| IP Rating | IP20 |
| Width | 17.5mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | 5SY4 |
| Terminal type | Combined Terminal |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2/UL1077 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 60V dc |
| Tripping Characteristics | Type D |
| Better World Claim | Extended Product Life |
| Curve C | Tripping: 5 to 10 times the rated current |
| Curve D | Tripping: 10 to 14 times the rated current |
Key Features
- Designed for 1-pole installation on DIN rail systems.
- Supports rated voltages of 400V AC and 60V DC.
- Features a high breaking capacity of 10 kA for fault current interruption.
- Combined terminal type ensures versatile connectivity.
- Compliance with IEC/EN 60898-1 and IEC/EN 60947-2 and UL1077 standards.
- IP20 rated for protection against solid objects and limited access.
- Suitable for industrial, residential, and functional construction applications.
- Extended product life under Siemens Better World sustainability initiative.
Product Description
Siemens 5SY4110-8 SENTRON Miniature Circuit Breaker delivers dependable protection with a Type D tripping curve and 10A current rating tailored for both AC and DC applications, rated at 400V AC and 60V DC. Designed for mounting on a DIN rail, this single-pole breaker offers a high breaking capacity of 10 kA, ensuring safe disconnection under fault conditions.
The compact design with dimensions of 90mm height, 17.5mm width, and 76mm depth makes it suitable for dense panel installations. The combined terminal provides flexible wiring options, enhancing installation convenience. This device is IP20 rated, providing protection against access to hazardous parts by fingers and compliance with international standards IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 assures quality and reliable performance.
Siemens SENTRON 5SY4 series combines advanced technical properties for industrial, functional building, and residential usage. This Miniature Circuit Breaker supports fast removal and installation on DIN rails, making maintenance efficient. The Type D characteristic curve is ideal for circuits with high inrush currents such as welders, transformers, and motors.
Reliable automatic cut-out protection with 10A current rating. Suitable for AC and DC voltages: 400V AC and 60V DC. High 10 kA breaking capacity for safety in fault conditions. Compact dimensions facilitate panel space saving.
Conforms to IEC and UL standards for safety and performance. Durable combined terminal ensures secure electrical connections. IP20 protection class safeguards against solid object intrusion. Easy DIN rail mounting for quick installation and removal.
Type D trip curve optimized for high-surge load applications.
As part of Siemens Better World initiative, this MCB boasts an extended product life contributing to sustainability goals. Its robust construction and versatile features make it suitable for use across industrial, residential, and commercial electrical systems where reliable circuit protection is critical.
Explore more circuit protection solutions and Siemens products on EnvMart for industry-leading quality and performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a breaking capacity of 10 kA, ensuring safe disconnection under fault conditions.
This model supports rated voltages of 400V AC and 60V DC.
The current rating for this miniature circuit breaker is 10A.
It is designed for mounting on DIN rail systems, allowing for easy installation and removal.
It has dimensions of 90mm in height, 17.5mm in width, and 76mm in depth.
This circuit breaker has a Type D tripping characteristic, optimized for circuits with high inrush currents.
It is rated IP20, providing protection against access to hazardous parts by fingers.
It complies with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077 standards.
It features a combined terminal type, which ensures versatile connectivity options.
This miniature circuit breaker is suitable for industrial, residential, and functional construction applications.
The Better World claim indicates that this model has an extended product life, contributing to sustainability goals.
This model belongs to the SENTRON series, specifically the 5SY4 series.
