Microchip MCP9700A Series Analogue Output Thermistor IC, Surface Mount, ±2 % Accuracy, 5-Pin SC-70 MCP9700A
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±2 % |
| Brand | Microchip |
| Height | 1mm |
| Length | 2.25mm |
| Model | MCP9700A |
| Width | 1.35mm |
| Mount Type | Surface |
| Output type | Analogue |
| Series | MCP9700A |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70 |
| Sub Type | Temperature Sensor |
| Minimum Operating Temperature | -40°C |
| Interface Type | Analogue |
| Pin Count | 5 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.3V |
| Sensor Gain | 10mV/°C |
| Linear Temperature Slope | 10mV/°C |
| Very low Operating Current | 12μA (max) |
Key Features
- Offers a linear temperature slope of 10mV/°C for precise measurements.
- Operates across a wide temperature range from -40°C to 125°C.
- Features a space-saving 5-pin SC-70 surface mount package.
- Requires no external components due to integrated design.
- Consumes very low power with a maximum operating current of 12μA.
- Operates from a supply voltage range of 2.3V to 5.5V.
- Includes a 500mV offset voltage enabling measurement of negative temperatures without negative supply.
- Ideal for space-critical and low-cost temperature sensing applications.
Product Description
Microchip MCP9700A Analogue Output Thermistor IC, model MCP9700A, is designed for accurate temperature sensing in industrial and commercial electronic devices. It outputs an analogue voltage linearly proportional to the measured temperature, calibrated at a slope of 10mV per degree Celsius.
This thermistor IC supports operating temperatures from -40°C up to a maximum of 125°C, making it suitable for a variety of environments. The device requires no external components and features a 5-pin SC-70 surface mount package, optimal for space-saving designs.
With a very low maximum operating current of 12μA and an operating supply voltage between 2.3V and 5.5V, it offers energy-efficient performance. The 500mV DC offset voltage enables the reading of negative temperatures without the need for a negative power supply. Its precision accuracy of ±2 % ensures reliable measurement data for critical applications.
This thermistor IC is widely applicable in industrial automation, HVAC systems, environmental monitoring, and instrumentation requiring robust and accurate temperature sensing. Linear temperature output of 10mV/°C. Temperature range from -40°C to 125°C.
Surface mount SC-70 5-pin package for compact integration. Low power consumption with 12μA maximum current. Wide supply voltage range from 2.3V to 5.5V. Calibrated for ±2 % accuracy. No external components required. Supports negative temperature sensing via DC offset.
Explore the full range of Temperature Sensor ICs on EnvMart for reliable industrial and laboratory temperature measurement solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates across a temperature range from -40°C to 125°C, making it suitable for various environments.
The MCP9700A has a precision accuracy of ±2 %, ensuring reliable measurement data for critical applications.
It features an analogue output type, providing a voltage that is linearly proportional to the measured temperature.
The device operates within a supply voltage range of 2.3V to 5.5V, allowing for flexible integration into various systems.
It has a very low maximum operating current of 12μA, making it energy-efficient for temperature sensing applications.
The MCP9700A offers a linear temperature slope of 10mV/°C for precise temperature measurements.
This model is housed in a 5-pin SC-70 surface mount package, which is optimal for space-saving designs.
No, it requires no external components due to its integrated design, simplifying the implementation process.
The MCP9700A has a height of 1mm and a width of 1.35mm, making it compact for various applications.
Yes, it includes a 500mV offset voltage that enables measurement of negative temperatures without the need for a negative supply.
This thermistor IC is widely applicable in industrial automation, HVAC systems, environmental monitoring, and instrumentation requiring accurate temperature sensing.
The MCP9700A is manufactured in India, ensuring compliance with local standards.
