TE Connectivity AMPMODU Shunt Straight Female Black Open Top 2 Way 1 Row 2.54 mm Pitch 390088-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Black |
| Orientation | Straight |
| Length | 4.98mm |
| Model | 390088-1 |
| Depth | 6.27mm |
| Width | 2.44mm |
| Contact Material | Phosphor Bronze |
| Series | AMPMODU |
| Sub Type | Open Top |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 2 |
| Connector Gender | Female |
| Maximum Contact Resistance | 20mΩ |
Key Features
- Supports 2 contacts with a 2.54 mm pitch for precise spacing.
- Features a black open top design for easy inspection and maintenance.
- Constructed with phosphor bronze contacts plated with gold over nickel for enhanced conductivity and corrosion resistance.
- Straight orientation ensures straightforward installation onto compatible headers.
- Compact size with 4.98 mm length, 2.44 mm width, and 6.27 mm depth for space-saving PCB layouts.
- Maximum contact resistance of 20 milliohms ensures minimal signal loss.
- Part of the AMPMODU series, compatible with a wide range of connectors and accessories.
- Ideal for industrial, automation, electronic component manufacturing, and testing applications.
Product Description
TE Connectivity 390088-1 AMPMODU Shunt Straight Female Black Open Top 2 Way 1 Row 2.54 mm Pitch is a high-quality electronic component intended for efficient and reliable PCB jumper connections. The shunt features a female connector design with two contacts arranged in a single row, spaced at a 2.54 mm pitch, matching standard PCB header specifications.
The contacts are made from phosphor bronze and plated with gold over nickel, delivering excellent electrical conductivity, corrosion resistance, and durability for extended lifespan in demanding industrial and electronic environments. The shunt's black color and open top style facilitate visual inspection and straightforward assembly or disassembly as needed within circuits.
With dimensions of 4.98 mm length, 2.44 mm width, and 6.27 mm depth, this AMPMODU shunt is compact and designed for space-efficient PCB layouts. Its maximum contact resistance is limited to 20 milliohms, ensuring low electrical resistance and reliable signal transfer across connections. The straight orientation of the connector aligns with standard PCB mounting requirements, making installation simple and exact.
This product is part of the AMPMODU series by TE Connectivity, providing compatibility with various accessories and housing modules to support customization, strain relief, and locking features. It is suitable for use in industrial automation, electronic manufacturing, telecommunications, and other electronic module applications where secure jumpers and shunts are necessary.
Supports 2 contacts with 2.54 mm pitch. Open top black housing for ease of access and inspection. Phosphor bronze contacts with gold over nickel plating for durability. Straight orientation designed for standard PCB header connection.
Compact dimensions ideal for dense electronic layouts. Maximum contact resistance of 20 milliohms for low loss. Compatible with AMPMODU accessories for additional functionality. Explore TE Connectivity products and AMPMODU connectors in the Electronics & Electricals category on EnvMart for comprehensive solutions addressing your PCB connector needs.
Explore more products in our Jumpers & Shunts category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts in this shunt are spaced at a 2.54 mm pitch, which is standard for PCB header specifications.
The contacts are made from phosphor bronze and are plated with gold over nickel, providing enhanced conductivity and corrosion resistance.
This shunt has dimensions of 4.98 mm in length, 2.44 mm in width, and 6.27 mm in depth, making it compact for space-saving PCB layouts.
The maximum contact resistance is 20 milliohms, ensuring minimal signal loss across connections.
This product features a female connector design, suitable for connecting to compatible headers.
This shunt supports 2 contacts, arranged in a single row.
The shunt has a straight orientation, designed for straightforward installation onto standard PCB headers.
This product is manufactured in India.
This shunt is part of the AMPMODU series by TE Connectivity, allowing compatibility with various accessories.
The housing of this shunt is black, featuring an open top design for easy inspection and maintenance.
This model is suitable for applications in industrial automation, electronic manufacturing, telecommunications, and testing.
The open top design facilitates visual inspection and straightforward assembly or disassembly within circuits.
