TE Connectivity AMPMODU Shunt Straight Female Black Open Top 2 Way 1 Row 5.08 mm Pitch 531230-3
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Colour | Black |
| Orientation | Straight |
| Current | 3A |
| Length | 87.7mm |
| Model | 531230-3 |
| Depth | 2.54mm |
| Width | 6.35mm |
| Housing Material | Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | AMPMODU |
| Sub Type | Open Top |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector Gender | Female |
| Maximum Contact Resistance | 15mΩ |
Key Features
- The shunt features a straight orientation with a black open top housing made of 94V-0 rated polyester glass-filled material.
- It has 2 female contacts arranged in a single row with a standard 5.08 mm pitch.
- Contacts are made from beryllium copper alloy and plated with gold over nickel for superior conductivity and corrosion resistance.
- The shunt offers a maximum contact resistance of 15 milliohms to ensure minimal signal loss.
- The product complies with no specific approvals but is engineered to meet standard connector quality requirements.
- It is stackable and constructed as one-piece for ease of use and durability.
- Its straightforward and robust design suits industrial electronic assemblies and automation control applications.
Product Description
TE Connectivity 531230-3 AMPMODU Shunt Straight Female is a high quality electronic connector designed for applications requiring reliable and efficient PCB connections. This shunt is part of the AMPMODU series and features a low profile, 5.08 mm pitch housing with an open top design that facilitates ease of installation and maintenance.
Constructed from black polyester glass-filled 94V-0 rated material, the housing ensures durability and electrical insulation. The contacts are formed from beryllium copper alloy and plated with gold over nickel to provide excellent conductivity and corrosion resistance, maintaining signal integrity over extended use.
With a current rating of 3A and voltage rating up to 250V, this shunt is suitable for numerous industrial, automation, and electronic control applications. The 2 female contacts arranged in a single row with a 5.08 mm pitch allows for compatibility with standard AMPMODU connectors.
The compact dimensions of 87.7 mm length, 6.35 mm width, and 2.54 mm depth make it suitable for space-constrained PCB layouts. The maximum contact resistance of 15 milliohms ensures low electrical resistance and reliable signal transmission.
This shunt's robust construction with a one-piece design enhances mechanical strength and stacking capability for modular applications. Although it carries no specific certifications, it meets standard industry quality expectations for PCB connectors and jumpers.
The shunt features a straight black open top housing made of 94V-0 rated polyester glass-filled material. 2 female contacts utilize beryllium copper alloy with gold over nickel plating. Designed for a maximum contact resistance of 15 milliohms for reliable connections.
Rated for 3A current and 250V voltage in industrial electronic environments. Compact size fits standard PCBs with 5.08 mm pitch and 1 row arrangement. Durable one-piece construction allows stacking in multi-connector setups.
Ideal for industrial, automation, laboratory, and power connector applications requiring stable jumpers. It is popular for use in industrial automation, power supply distribution, and PCB connector assemblies. Explore EnvMart's wide range of electronic connectors and jumpers to find complementary components for your industrial and manufacturing needs.
Explore more products in our Jumpers & Shunts category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The shunt has a maximum voltage rating of 250V, making it suitable for various industrial applications.
This model is rated for a maximum current of 3A, which is appropriate for many electronic control applications.
The housing is made of polyester glass-filled material rated at 94V-0, while the contacts are formed from beryllium copper alloy and plated with gold over nickel.
The contacts are arranged with a standard pitch of 5.08 mm, allowing compatibility with AMPMODU connectors.
The shunt measures 87.7 mm in length, 6.35 mm in width, and 2.54 mm in depth, making it suitable for compact PCB layouts.
This model features 2 female contacts arranged in a single row.
The maximum contact resistance is 15 milliohms, ensuring minimal signal loss during operation.
Yes, the shunt is designed to be stackable, which enhances its modularity for multi-connector setups.
It is suitable for industrial, automation, laboratory, and power connector applications requiring stable jumpers.
The shunt features a straight orientation, which aids in installation and maintenance.
The shunt is manufactured in India.
This connector is part of the AMPMODU series, known for its reliable PCB connections.
