Vishay Single Layer Ceramic Capacitor 330 pF 3kV dc ±10% Tolerance S3N Dielectric Through Hole Radial F331K33S3NR63K7R

Vishay F331K33S3NR63K7R Single Layer Ceramic Capacitor is a high-quality Class I ceramic disc capacitor designed for industrial and electronic applications requiring low losses and high capacitance in a compact form factor. It features a capacitance of 330 pF and is rated for a maximum DC voltage of 3 kV, making it ideal for demanding circuits.

The capacitor utilizes an S3N dielectric material, known for its stability and performance in Switch Mode Power Supplies (SMPS), high-frequency ballast, snubber, and other high voltage circuits where reliability is critical. Its construction features silver-plated ceramic discs connected by tinned copper leads with a diameter of 0.6 mm to 0.8 mm, kinked for easy through-hole PCB mounting with lead spacing options of 5 mm, 7.5 mm, or 10 mm.

The epoxy resin encapsulation complies with the UL 94 V-0 flammability rating, ensuring safety during operation. Suitable for operating temperatures ranging from -30°C up to 125°C, this capacitor delivers stable performance under a wide range of environmental conditions. Its low dissipation factor of 0.2% minimizes energy losses, improving efficiency in power electronics and signal integrity in precision circuits.

High reliability ceramic disc capacitor designed for high frequency and high voltage circuits. Features a stable S3N Class I dielectric material suitable for SMPS, HF ballast, and snubber circuits. Kinked leads with lead spacing options support through hole mounting and ease of PCB insertion.

Silver-plated ceramic disc with epoxy resin encapsulation ensuring flame resistance (UL 94 V-0). Wide operating temperature range from -30°C to 125°C ensuring reliable performance. Low dissipation factor of 0.2% for minimal energy loss in circuits.

Radial terminal type with 2 pins and disc package for compact design. Compliant with RoHS and EC standards guaranteeing environmental safety. Class I suppression type capacitor offering excellent capacitance stability across temperature range.

Suitable for use in electronic, power supply, and industrial applications requiring high voltage capacitors.

This capacitor is widely used in industrial electronics, power supplies, HVAC control systems, manufacturing electronic modules, and electronic repair or prototype development. Its through-hole design also allows for easy integration into traditional PCB layouts.
