Ledil EVA Series 1-Way LED Lens Round Clear Polymethyl Methacrylate Material 22 to 26° Medium Angle Beam 35mm C10685_EVA-M

Free Delivery in India | Lowest Global Shipping Charges

Ledil EVA Series 1-Way LED Lens Round Clear Polymethyl Methacrylate Material 22 to 26° Medium Angle Beam 35mm C10685_EVA-M

Name: Ledil EVA Series 1-Way LED Lens Round Clear Polymethyl Methacrylate Material 22 to 26° Medium Angle Beam 35mm C10685_EVA-M
Brand: Ledil
SKU: 218232
Price: 3.42 USD
Availability: InStock



Category LED Lenses & Reflectors Brand Ledil Condition New

Specifications

Country of Origin	India
Diameter	35mm
Brand	Ledil
Height	16.4mm
Model	C10685_EVA-M
Series	EVA
Viewing angle	22 to 26°
Lens Material	Polymethyl Methacrylate
For Use With	Cree XP-G2, Nichia NS9x383, Cree MHB-A, Lumileds LUXEON M, Cree XT-E, Lumileds LUXEON 5258, Nichia NSMx286M, Cree MC-E, Lumileds LUXEON MZ, OSRAM Duris S8, Cree XM-L
Lens Shape	Round
Emission Pattern	Medium Angle
Number of LEDs Per Lens	1

Key Features

Constructed from optical grade polymethyl methacrylate for high UV and temperature resistance.
Designed for use with a single LED, compatible with several Cree, Nichia, Lumileds, and OSRAM LEDs.
Round lens shape with 35mm diameter and 16.4mm height.
Clear lens style provides uniform output with medium angle emission pattern.
Suitable for LED lighting applications requiring precise beam control.
Optimised for industrial, electronic components, and lighting solutions.

Product Description

Ledil C10685_EVA-M is a member of the EVA Series 1-Way LED Lenses designed to provide efficient light focusing with a medium angle emission pattern. This model features a clear lens made from high-quality polymethyl methacrylate (PMMA), known for its excellent optical properties, UV resistance, and high thermal stability. The lens measures 35mm in diameter and has a height of 16.4mm, making it suitable for compact LED lighting fixtures.

The lens is engineered to work with one LED per unit and supports a variety of LEDs including Cree XP-G2, Nichia NS9x383, Cree MHB-A, Lumileds LUXEON M, Cree XT-E, Lumileds LUXEON 5258, Nichia NSMx286M, Cree MC-E, Lumileds LUXEON MZ, OSRAM Duris S8, and Cree XM-L. The viewing angle of 22 to 26 degrees provides a medium beam suited for applications requiring controlled light dispersion.

Manufactured with precision, the lens is ideal for use in LED lighting components within electronic assemblies and devices. It enables a uniform output by directing light efficiently, improving the performance and efficacy of lighting systems.

Industrial applications encompass general LED lighting, electronic component integration, and specialized lighting equipment that demand durability and consistent optical output. The EVA series also includes versions with black PC holders and different beam angles, but this model features a clear lens for enhanced light transmission.

Constructed from optical grade polymethyl methacrylate for durability and UV resistance. Designed for single LED integration with multiple LED compatibility. Medium angle emission pattern for focused lighting applications.

Compact dimensions with 35mm diameter and 16.4mm height. Clear lens style for optimal light clarity and uniformity. This product is new, with no formal certification standards listed. Explore more LED lenses & reflectors and associated lighting components in the EnvMart catalog for industrial and commercial lighting solutions.
