Souriau Sunbank by Eaton SMS Female Connector Housing 12 Way 4 Row 5.08 mm Pitch Straight Cable Mount SMS12RDH3
Specifications
| Country of Origin | Belgium |
|---|---|
| Brand | Souriau Sunbank by Eaton |
| Orientation | Straight |
| Length | 38.1mm |
| Model | SMS12RDH3 |
| Width | 25.1mm |
| Mount Type | Cable |
| Housing Material | Polyamide |
| Series | SMS |
| Number of Rows | 4 |
| Pitch | 5.08mm |
| For Use With | Quick Mating Wire-to-Board Connector |
| Number of Contacts | 12 |
| Connector Gender | Female |
Key Features
- The connector housing features a straight orientation suited for cable mount applications.
- Constructed from flame retardant polyamide material compliant with railway fire and smoke standards.
- Incorporates a strain relief hood and discrimination cavities for enhanced cable retention and mating alignment.
- Compatible with size 16 TRIM TRIO snap-lock pin and socket contacts sold separately.
- Compact design facilitates quick assembly with a push-to-mate and press-and-release to unmate system.
- Meets railway standards I3/F2 according to NFF16101 & NFF16102 and HL3/R23 per EN45545 (2009).
Product Description
Souriau Sunbank by Eaton SMS12RDH3 is a female connector housing from the SMS series designed for quick mating cable mount applications with 12 contacts arranged in 4 rows and a 5.08 mm pitch. This straight cable mount connector housing is constructed from durable polyamide (PA 6 UL94-V0) that is flame retardant and smoke resistant, perfectly suited for demanding railway indoor environments.
The design features a compact form factor with dimensions of 38.1 mm in length and 25.1 mm in width, allowing for seamless integration into PCB assemblies. The connector incorporates a strain relief hood with discrimination cavities between contact cavities to prevent mismating and enhance mechanical performance.
Featuring a patented push-to-mate and press-and-release to unmate interconnection system, this housing enables rapid assembly and installation without additional hardware. It is designed to work with size 16 TRIM TRIO 1.6 mm diameter snap-lock pin and socket contacts, which are sold separately, ensuring reliable electrical connections.
Certified to railway fire and smoke standards I3/F2 under NFF16101 & NFF16102 and HL3/R23 according to EN45545 (2009), the SMS12RDH3 connector housing meets stringent safety requirements for railway and industrial use cases.
This connector housing is ideal for use in industrial, electronic components manufacturing, railway transportation systems, and any application requiring robust, fire-retardant quick mating connectors.
The connector housing features a straight orientation suited for cable mount applications. Constructed from flame retardant polyamide material compliant with railway fire and smoke standards. Incorporates a strain relief hood and discrimination cavities for enhanced cable retention and mating alignment.
Compatible with size 16 TRIM TRIO snap-lock pin and socket contacts (sold separately). Compact design facilitates quick assembly with a push-to-mate and press-and-release to unmate system. Dimensions include 38.1 mm length and 25.1 mm width for efficient PCB integration.
Meets railway standards I3/F2 according to NFF16101 & NFF16102 and HL3/R23 per EN45545 (2009). Explore more from Souriau Sunbank by Eaton connector solutions at EnvMart to suit your electronic Connector Housing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the Souriau Sunbank SMS12RDH3 connector housing is 5.08 mm.
This model supports 12 contacts arranged in 4 rows.
The housing is constructed from flame retardant polyamide material.
The dimensions of the SMS12RDH3 connector housing are 38.1 mm in length and 25.1 mm in width.
This connector housing is designed for cable mount applications.
The orientation of this connector housing is straight.
It is compatible with size 16 TRIM TRIO snap-lock pin and socket contacts, which are sold separately.
This model features a patented push-to-mate and press-and-release to unmate interconnection system for rapid assembly.
It meets railway fire and smoke standards I3/F2 according to NFF16101 & NFF16102 and HL3/R23 per EN45545 (2009).
The country of origin for this connector housing is Belgium.
This connector housing is suitable for use in industrial, electronic components manufacturing, and railway transportation systems.
The connector incorporates a strain relief hood and discrimination cavities to enhance cable retention and mating alignment.
