TE Connectivity Female Crimp Circular Connector Contact, Contact Size 20 AWG, Wire Size 8AWG, 45A, 630V AC, Silver 1318697-6
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 630V ac |
| Brand | TE Connectivity |
| Current | 45A |
| Length | 23.4mm |
| Gender | Female |
| Contact Material | Copper Alloy |
| Series | Dynamic 5000 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 105°C |
| Contact Type | Receptacle |
| Minimum Operating Temperature | -55°C |
| Wire size | 8AWG |
| For Use With | L Size Receptacle |
| Contact Plating | Silver over Nickel |
| Contact Size | 20 AWG |
Key Features
- Constructed with copper alloy for excellent conductivity and durability.
- Contact plated with silver over nickel to enhance corrosion resistance and electrical performance.
- Rated for 45 amperes current and 630 volts AC voltage capacity.
- Twist resistant box shape design provides mechanical reliability and secure connections.
- Designed for crimp termination ensuring strong and reliable wire attachment.
- Compatible for use with L Size Receptacles in Dynamic 5000 series connectors.
- Operates reliably in temperatures ranging from -55°C to 105°C.
Product Description
TE Connectivity 1318697-6 Female Crimp Circular Connector Contact is a high-performance component designed for demanding electrical and industrial applications. This connector contact features a 20 AWG contact size and is designed for wires sized 8AWG, enabling it to carry currents up to 45 amperes and withstand voltages up to 630 volts AC.
Manufactured from copper alloy, the contact ensures exceptional electrical conductivity and mechanical strength. The silver plating over nickel of the contact surface improves corrosion resistance, ensuring longevity and reliable electrical performance under various conditions.
The design includes a twist resistant box shape and three points of contact, which ensure a secure, vibration-resistant connection. This contact is part of the Dynamic 5000 series, aimed at high current power line applications, and it is intended for crimp termination, offering a robust and efficient wire termination method.
With a contact length of 23.4 mm, it is optimized for compatibility with L Size Receptacles. The connector operates efficiently across a wide temperature range from -55°C to 105°C, making it suitable for use in harsh industrial, automotive, and manufacturing environments.
Constructed with copper alloy for excellent conductivity and durability. Contact plated with silver over nickel to resist corrosion and improve performance. Supports a current rating of 45 amperes and voltage rating of 630 volts AC.
Twist resistant box shape design ensures reliable mechanical and electrical connection. Crimp termination for secure wire attachment. Compatible with L Size Receptacles, Dynamic 5000 series connectors. Wide operating temperature range from -55°C to 105°C.
Length of 23.4 mm for robust insulation and connectivity.
This connector contact finds applications in industrial machinery, electrical distribution, power connectors, and other commercial electronic assemblies requiring high current and reliable connections. TE Connectivity provides a durable solution with advanced plating and material quality, ideal for maintenance and assembly operations in harsh environments.
Explore related Circular Connector Contacts and connectors at EnvMart for comprehensive solutions in electrical connectivity.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector contact is rated for a maximum current of 45 amperes and can withstand voltages up to 630 volts AC.
The contact size is 20 AWG, and it is designed for use with wires sized 8 AWG.
The contact is constructed from copper alloy, which provides excellent conductivity and mechanical strength.
It uses crimp termination, which ensures a strong and reliable wire attachment.
The length of this connector contact is 23.4 mm.
This connector operates reliably in temperatures ranging from -55°C to 105°C.
It is compatible with L Size Receptacles in the Dynamic 5000 series connectors.
The contact is plated with silver over nickel, enhancing its corrosion resistance and electrical performance.
The twist resistant box shape design provides mechanical reliability and secure connections, ensuring a vibration-resistant connection.
This connector contact is suitable for use in industrial machinery, electrical distribution, power connectors, and other commercial electronic assemblies requiring high current connections.
The country of origin for this connector contact is India.
This connector contact is part of the Dynamic 5000 series, designed for high current power line applications.
