Eaton Ceramic Cartridge Fuse 5A Current Rating 10 x 38 mm 1kV DC PV Series PV-5A10F

Eaton PV-5A10F Ceramic Cartridge Fuse is engineered for photovoltaic applications requiring a current rating of 5A and a voltage rating of 1kV DC. This fuse offers effective protection and isolation for photovoltaic strings, critical in solar power systems.

The fuse has a robust ceramic body sized at 10 x 38 mm, classified as a compact midget size, ideal for space-saving installations without compromising performance. It features an impressive high breaking capacity of 40 kA, safeguarding electrical circuits against fault currents and short circuits.

Designed according to IEC 60269 standards, the PV-5A10F ensures compliance with international safety and quality norms including CCC, CSA, and UL certifications. It is suitable for use with various solar cell technologies including thin film and crystalline silicon cells of sizes 4, 5, and 6 inches.

Installation flexibility is enhanced by compatibility with a range of fuse holders such as PCB clips and modular types. The product supports fault current interruption in photovoltaic string arrays, making it an excellent choice for solar panel protection and coordination.

This fuse effectively protects photovoltaic string arrays from electrical faults and overcurrents. Compact ceramic body suitable for high-capacity photovoltaic systems. Conforms to relevant international safety standards.

High breaking capacity ensures reliable operation and safety. Compatible with multiple fuse holders for versatile application. Designed for use across different solar cell technologies and configurations. Facilitates efficient and space-saving installation in solar power systems.

Ideal for industrial, manufacturing, and renewable energy sectors, Eaton’s PV-5A10F fuse is a reliable component for solar power protection. Explore more high-quality Cartridge Fuses and related products in the Circuit Breakers & Fuse category at EnvMart.
