Preci-Dip 9 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, 3A, Solder 310-87-109-01-640101

Preci-Dip 310-87-109-01-640101 is a 9 Way SIL Socket designed for electronic applications requiring 2.54 mm pitch and straight through hole mounting. This socket features 9 brass and beryllium copper alloy contacts with flash gold plating and tin plated brass sleeves, ensuring excellent conductivity and corrosion resistance. Its housing is crafted from fibreglass reinforced Polycyclohexylenedimethylene Terephthalate, providing mechanical durability and thermal stability.

The socket supports a current rating of 3 amps and a voltage rating of up to 150V dc, making it suitable for a range of power and signal applications in industrial and electronic equipment. Termination is done by soldering, which creates reliable and robust electrical connections.

Designed with pin diameters of 0.47 mm and a pin length of 3.2 mm in standoff through hole format, installation onto printed circuit boards is straightforward and secure. It reliably operates in temperature ranges from -55°C low extremes up to 125°C high extremes, accommodating demanding operational environments.

This compact socket measures 22.86 mm in length, with a width and pitch of 2.54 mm, and depth of 4.2 mm, allowing for precise board layouts. It is manufactured in Switzerland under high quality standards but does not carry specific certifications or approvals.

9 contacts made from brass and beryllium copper alloy. Gold and tin plating for corrosion resistance and conductivity. 2.54 mm pitch with straight orientation for precise connection. Fibreglass reinforced housing with robust mechanical properties.

Operating temperature from -55°C to 125°C. Solder termination for stable connections. 150V dc voltage and 3A current rating. Compact size optimized for PCB integration. Manufactured in Switzerland ensuring quality.

This Preci-Dip SIL Socket is ideal for use in manufacturing, electronics assembly, industrial control systems, and laboratory instrumentation where secure, high-quality electrical connections are needed. It enhances production efficiency by enabling reliable component mating and ease of installation.
