Preci-Dip 12 Way Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, 3A, Solder Termination 801-87-012-10-012101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 12 Way Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, 3A, Solder Termination 801-87-012-10-012101

Name: Preci-Dip 12 Way Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, 3A, Solder Termination 801-87-012-10-012101
Brand: Preci-Dip
SKU: 215453
Price: 1.99 USD
Availability: InStock



Category SIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V dc
Brand	Preci-Dip
Orientation	Straight
Current	3A
Length	30.48mm
Depth	4.2mm
Width	2.54mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Beryllium Copper Alloy, Brass
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	12

Key Features

Equipped with 12 contacts for reliable signal transfer.
Contacts made from beryllium copper alloy and brass for durability.
Contact plating includes tin and gold for corrosion resistance.
Housing constructed of fibreglass reinforced polycyclohexylenedimethylene terephthalate.
Termination via solder ensures secure connection.
Operating temperature range from -55°C to 125°C for versatile environments.
Designed for through hole mounting with straight contact orientation.
Meets UL 94V-0 flammability standard.

Product Description

Preci-Dip 801-87-012-10-012101 12 Way SIL Socket is engineered for electronic applications requiring reliable connection at 2.54 mm pitch and 150V dc voltage rating with 3A current capacity. It features a robust construction utilizing beryllium copper alloy and brass contact materials with tin and gold plating to ensure excellent conductivity and corrosion resistance.

The socket's housing is made of fibreglass reinforced polycyclohexylenedimethylene terephthalate, providing durability and stability. Its solder termination type and through hole mounting style enable effective and secure integration on printed circuit boards. The contact clips incorporate a 4-finger design to maintain excellent spring force and connection reliability.

Operating reliably from -55°C to 125°C, this SIL socket is suitable for demanding industrial and electronic environments. Its compact form factor with dimensions of 30.48 mm length, 2.54 mm width, and 4.2 mm depth makes it ideal for PCB assemblies requiring standard 2.54 mm pitch spacing.

The product complies with UL 94V-0 standards ensuring flame retardancy. Manufactured in Switzerland, this Preci-Dip socket delivers superior quality and consistency. Equipped with 12 electrical contacts inside the socket.

Contact materials combine mechanical strength and conductivity. Tin and gold plating protects contacts against oxidation. Housing material supports mechanical and thermal stability. Standard pitch spacing of 2.54 mm facilitates compatibility.

Solder termination guarantees strong PCB connection. Wide operating temperature range makes it suitable for various applications. Compliant with UL 94V-0 flammability standard. Swiss origin assures premium manufacturing excellence.

This SIL socket is widely used in electronics manufacturing, industrial automation, and PCB assembly applications. Its precise pin spacing and robust contact design support enhanced signal integrity and long service life.
