Preci-Dip 5 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 150V dc, Solder, 3A 801-87-005-10-012101

Preci-Dip 801-87-005-10-012101 is a 5 Way SIL (Single Inline) Socket designed for electronic components requiring reliable PCB connections. It features a 2.54 mm pitch and straight through-hole mounting, ideal for insertion into printed circuit boards in industrial and commercial electronics assembly.

The socket incorporates brass and beryllium copper alloy contacts plated with gold and tin for superior electrical performance and corrosion resistance. The durable fibreglass reinforced polycyclohexylenedimethylene terephthalate housing ensures stability and high temperature tolerance up to 125°C.

With a current rating of 3A and a voltage rating of 150V DC, this component supports a broad range of electronic applications including industrial control systems, instrumentation, and PCB interfaces.

Contact construction from brass and beryllium copper alloy for reliable conductivity. Gold and tin plating ensures low contact resistance and long life. Fibreglass reinforced housing supports thermal and mechanical durability.

Operates effectively within temperature range -55°C to 125°C. Pin pitch of 2.54 mm conforms to standard PCB design requirements. Straight orientation and through-hole mount facilitate easy assembly and soldering. Compact dimensions: length 12.7 mm, width 2.54 mm, depth 4.2 mm.

Manufactured in Switzerland, meeting stringent quality standards. Ideal for electronics manufacturing, testing, and repair environments. Suitable for use in industrial, laboratory, and commercial electronic systems.

This SIL socket is a key component in PCB connector assemblies, enhancing production efficiency and ensuring consistent electrical connections. It is also RoHS compliant, offering environmentally friendly construction.
